10
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Default:
XX
EQ SETTING
PRESET EQ
Select a preset equalizer suitable to the music genre.
•
Select
[USER]
to use the settings made in
[EASY EQ]
or
[PRO EQ]
.
FLAT
/
DRVN 3
/
DRVN 2
/
DRVN 1
/
HARD ROCK
/
HIP HOP
/
JAZZ
/
POP
/
R&B
/
TALK
/
USER
/
VOCAL BOOST
/
BASS BOOST
/
CLASSICAL
/
DANCE
EASY EQ
Adjust your own sound settings.
•
The settings are stored to
[USER]
.
•
The settings made may affect the current settings of
[PRO EQ]
.
SUB.W SP
*
1
*
2
:
00
to
+06
(Default:
+03
SUB.W
*
1
*
3
:
–08
to
+08
00
BASS
:
LVL–06
to
LVL+06
LVL 00
MID
:
LVL–06
to
LVL+06
LVL 00
TRE
:
LVL–06
to
LVL+06
LVL 00
)
PRO EQ
1
BASS
/
MIDDLE
/
TREBLE
:Select a sound tone.
2
Adjust the sound elements of the selected sound tone.
•
The settings are stored to
[USER]
.
•
The settings made may affect the current settings of
[EASY EQ]
.
BASS
Frequency:
60HZ
/
80HZ
/
100HZ
/
200HZ
(Default:
80HZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q1.0
/
Q1.25
/
Q1.5
/
Q2.0
Q1.0
)
MIDDLE
Frequency:
0.5KHZ
/
1.0KHZ
/
1.5KHZ
/
2.5KHZ
(Default:
1.0KHZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q0.75
/
Q1.0
/
Q1.25
Q1.25
)
TREBLE
Frequency:
10.0KHZ
/
12.5KHZ
/
15.0KHZ
/
17.5KHZ
(Default:
10.0KHZ
Level:
LVL–06
to
LVL+06
LVL 00
Q:
Q FIX
Q FIX
)
AUDIO SETTINGS
AUDIO CONTROL
BASS BOOST
LEVEL +01
to
LEVEL +05
(
LEVEL +01
): Selects your preferred
bass boost level.;
OFF
:Cancels.
LOUDNESS LEVEL 01
/
LEVEL 02
:Boosts low or high frequencies to produce a
well-balanced sound at low volume.;
OFF
:Cancels.
SUB.W LEVEL
*
1
SPK-OUT
*
2
SUB.W 00
to
SUB.W +06
(
SUB.W +03
):Adjusts
the output level of the subwoofer connected via
speaker lead.
( 17)
PRE-OUT
*
3
SUB.W –08
to
SUB.W +08
(
SUB.W 00
):Adjusts
the output level of the subwoofer connected to the
lineout terminals (REAR/SW) through an external
amplifier.
( 17)
SUBWOOFER SET
*
3
ON
: Turns on the subwoofer output.;
OFF
: Cancels.
SUBWOOFER
LPF
*
1
FRQ THROUGH
:All signals are sent to the subwoofer;
FRQ 55HZ
/
FRQ 85HZ
/
FRQ 120HZ
:Audio signals with frequencies
lower than 55Hz/85Hz/120Hz are sent to the subwoofer.
SUB.W PHASE
*
1
*
4
REVERSE
(180°)/
NORMAL
(0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum
performance.
FADER POSITION R06
to
POSITION F06
(
POSITION 00
):Adjusts the front
and rear speaker output balance.
BALANCE
*
5
POSITION L06
to
POSITION R06
(
POSITION 00
):Adjusts the left
and right speaker output balance.
*
1
Displayed only when
[SUBWOOFER SET]
is set to
[ON]
.
*
2
Displayed only when
[SPK/PRE OUT]
is set to
[SUB.W/SUB.W]
.
( 11)
*
3
Displayed only when
[SPK/PRE OUT]
is set to
[REAR/SUB.W]
or
[SUB.W/SUB.W]
.
( 11)
*
4
Selectable only if a setting other than
[FRQ THROUGH]
is selected for
[SUBWOOFER LPF]
.
*
5
This adjustment will not affect the subwoofer output.
