![Gigabyte GA-J3355N-D2P [4/31] Ga j3355n d2p](/img/pdf.png)
Gigabyte GA-J3355N-D2P [4/31] Ga j3355n d2p
![Gigabyte GA-J3355N-D2P [4/31] Ga j3355n d2p](/views2/1267627/page4/bg4.png)
- 4 -
GA-J3355N-D2P Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-J3355N-D2P motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
CPU_FAN
ATX
GA-J3355N-D2P
AUDIO
SODIMM_1
BAT
ATX_12V
Intel
®
Apollo Lake J3355
CODEC
B_BIOS
VGA
R_USB30
HDMI
PCI
F_PANEL
SPEAKER
COMB
LPT
COMA
Realtek
®
GbE LAN
iTE
®
Super I/O
SYS_FAN
CLR_CMOS
USB30_LAN
F_AUDIO
CI
F_USB1
F_USB2
SATA3 0 1
PCIe to
PCI Bridge
TPM
SODIMM_2
SPDIF_O
M_BIOS
BIOS_SET
