your kitchen cooker exhaust device in accordance with table 1 If the problem has not been dissolved apply to the service center Serving and spare parts You may acquire spare parts at an authorized service center The service center number is shown in the guarantee coupon When applying to the service center to order any spare parts report the device number and its model as indicated in the device label 4 Screwing on the hooks Screw on clockwise direction in the dowels A B C and D 8 mm in diameter you have placed in the wall the distance between the wall and hook shall be 5 mm Screw on the bar of the air pipe decorative box to the dowels E and F 6 mm in diameter you have placed in the wall 5 Place the plastic connecting flange with the anti reciprocal valve in the according place at the top of the exhaust device with the help of two screws 3 5 x 9 5 6 Hang the kitchen exhaust device body on the abutment hooks A and B 7 Put the flexible air pipe is not supplied on the anti reciprocal valve 8 Hang the kitchen cooker exhaust device on the abutment hooks 9 Fix the kitchen cooker exhaust device with screws M 5 5 x 45 from inside the body as shown in the figure 10 Connect the air pipe to the ventilation hole in the wall 11 Connect the kitchen cooker exhaust device to the electric network and prepare it for working Notes I 1 Provide that the electric socket to be easily accessable to disconnect tl e exhaust device in case of necessity 2 Dimensions of the holes to be perforated when assembling the exhaust device must correspond to the ones shown in the figure Using the device Choosing the speed i The kitchen cooker exhaust device has three speed electric motor and multi positk ri electronic switch to control the electric motor For the best quality of working we recommend you to exploit the device at the higher speed at the moment of increased content of smoke and smells The kitchen cooker exhaust device should be switched on a few minutes befo e preparing meals and work continuously after completing preparing meals util smoke and smells disappear We recommend you to use the timer function Lighting The kitchen cooker exhaust device has two lamps and is controlled with the lighting button on the electronic control block i Efficient ventilation 14 i The outer windows in the premises should be closed for correct ventilation The doors and windows to the inner premises may be opened
