V-AVM700

Installation

• Be sure to connect the color-coded leads according to the diagram. Incorrect connections may cause the unit

to malfunction or damage the vehicle’s electrical system.

• Be sure to connect the speaker (-) leads to the speaker (-) terminal. Never connect the left and right channel

speaker cables to each other or to the vehicle body.

• Make sure all the connections are completely correct before turning on your unit.

• When replacing the fuse(s), the replacement must be of the same amperage as shown on the fuse holder.

• Do not block vents or radiator panels. Blocking them will cause heat to build up inside and may result in fire.

• After completing the installation, please press RESET button on the unit with pointed object (such as ball-

point pen) to set the unit to initial status.

• Use only the parts included with unit to ensure proper installation. The use of unauthorized parts can cause

malfunction.

• Consult with your nearest dealer if installation requires the drilling or other modifications of the vehicle.

• Install the unit where it does not interfere with driver’s actions and cannot injure the passenger if there is a

sudden stop, like an emergency stop.

• The semiconductor laser will be damaged if it overheats, so don't install the unit in hot place, for example,

near a heater outlet.
