4
FEATURES
1. Dolby Digital
Using advanced digital processing algorithms, Dolby Digital
provides up to 5.1 channels of wide-range, high fidelity surround
sound. Dolby Digital is the default digital audio delivery system for
DVD and North American DTV.
2. Dolby Pro Logic
IIx compatibility
Dolby Pro Logic IIx furthers the matrix decoding technology of
Dolby Pro Logic II to decode audio signals recorded on two
channels into up to 7.1 playback channels, including the surround
back channel. Dolby Pro Logic IIx also allows 5.1-channel sources
to be played in up to 7.1 channels.
The mode can be selected according to the source. The Music
mode is best suited for playing music,the Cinema mode for playing
movies, and the Game mode for playing games. The Game mode
can only be used with 2-channel audio sources.
3. Dolby Pro Logic
II Game mode compatibility
In addition to the previously offered Music and Cinema modes, the
AVR-2105/885 also offers a Game mode optimum for games.
4. DTS (Digital Theater Systems)
DTS provides up to 5.1 channels of wide-range, high fidelity
surround sound, from sources such as laser disc, DVD and
specially-encoded music discs.
5. DTS-ES Extended Surround and DTS Neo:6
The AVR-2105/885 can be decoded with DTS-ES Extended
Surround, a multi-channel format developed by Digital Theater
Systems Inc.
The AVR-2105/885 can be also decoded with DTS Neo:6, a
surround mode allowing 6.1 channels playback of regular stereo
sources.
6. DTS 96/24 compatibility
The AVR-2105/885 can be decoded with sources recorded in DTS
96/24, a multi-channel digital signal format developed by Digital
Theater Systems Inc.
DTS 96/24 sources can be played in the multi-channel mode on the
AVR-2105/885 with high sound quality of 96 kHz/24 bits or 88.2
kHz/24 bits.
7. Auto Setup
Use of the microphone for setup applications measures the
presence of speakers, the distance to the speakers, and other
information, and permits automatic setup. The characteristics of
each speaker can also be corrected.
8. Multi Zone Music Entertainment System
Multi Source Function:
This unit’s Multi Source function lets you select different audio
sources for listening Different sources can thus be enjoyed in the
main room (MAIN) and the subroom (ZONE2) simultaneously.
9. Future Sound Format Upgrade Capability via Eight Channel
Outputs
For future multi-channel audio format(s), the AVR-2105/885 is
provided with 5.1 channel (five main channels, plus one low
frequency effects channel) inputs, along with a full set of 7.1
channel pre-amp outputs, controlled by the 8 channel master
volume control. This assures future upgrade possibilities for any
future multi-channel sound format.
10.Front input Terminal
The unit is equipped with a Front Input connector for the
convenient connection of a video camera or other equipment.
11.Video Conversion Function
The AVR-2105/885 is equipped with a function for up-converting
video signals.
Because of this, the AVR-2105/885’s MONITOR OUT jack can be
connected to the monitor (TV) with a set of cables offering a higher
quality connection, regardless of how the player and the AVR-
2105/885’s video input jacks are connected.
12.Component Video Switching
In addition to composite video and “S” video switching, the AVR-
2105/885 provides 3 sets of component video (Y, P
B/CB, PR/CR)
inputs, and one set of component video outputs to the television,
for superior picture quality.
13.Auto Surround Mode
This function stores the surround mode last used for an input
signal in the memory and automatically sets that surround mode
the next time that signal is input.
14.Preset Memory Tuning
56-Station AM/FM Random Preset Memory tuning.
15.On Screen Display
Troublesome operations such as adjusting the delay time and other
parameters according to the listening environment are greatly
simplified. The various parameters can be set simply by selecting
the graphic displayed on the monitor screen according to the
listening room’s system environment.
6
ENGLISH
