10
TECHNICAL PASSPORT ENGLISH
Gas oven
Installation Location
In order for the gas unit to work
properly it is essentital that the air
necessary for burning the gas ows into
the area naturally.
The installer must follow the safety
norms for the country of installation.
The ow of air into the area must
come directly througy openings made in
the exterior walls. These openings must
have a free passage section of at least
100 cm2 (one or more openings can be
made.)
Products of combustion must be
exhausted through a hood connected to
a fume ue or directly outside.
In the event that it is not possible to
install the hood, it is necessary to use
an electric ventilation fan installed in
the outside wall or window of the area
so long as there is an opening for air
to enter the area in conformity with
current law.
This electric ventilation fan must
have a ow capacity sufcient to
guarantee that 3 to 5 times the volume
of air in the room is xechanged every
hour.
Electrical Connection
Attention: do not connect to the
power supply before you have nished
connecting the oven and cooktop.
Make sure that installation and
hook-up are performed by a qualied
technician in accordance with the
manufacturer’s instructions and in
compliance with local regulations. The
installer is responsible for the correct
electrical connection and for the
observance of the safety rules.
The oven must be connected to the
electricity supply by means of an all-
pole disconnect switch with minimum
contact gap of 3 mm. The appliance
must be earthed by law.Do not use
multiple sockets or extensions.After the
oven has been installed, the electrial
componenets must be inaccessible.
Make sure that the voltage stated
on te appliance rating plate is the same
as the voltage in your home. The rating
plate is on the lower front edge of the
oven (visible with the door open.) If teh
power supply cable needs replacing,
make sure that it is replaced with a
cable similar to the one provided by
the Manufacturer (H05 RR-F type) and
that installation is performed by Service
Center or a qalied technician. The
appliance is equipped with the cable for
the elecrical connection without plug.
The wires in the mains supply lead
are coloured in accordance with the
following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
The connection must be made
as follows: The wire coloured Green
and Yellow must be connected to
the terminal marked ‘E’ or the earth
symbol or coloured green or green
and yellow. The wire coloured Blue
