34
Congratulations on your purchase of the Bosch Athlet
vacuum cleaner.
This instruction manual describes various Athlet mo-
dels, which means that some of the equipment features
and functions described may not apply to your model.
You should only use original Bosch accessories, which
have been specially developed for your vacuum clea-
ner, in order to achieve the best possible vacuuming
results.
Please fold out the picture pages.
1 Floor tool with electric brush
2 Dust container
3 Dirt container release button
4 Battery charging status indicator
5 Sensor Control indicator
6 Dust container
7 Outer filter unit
8 Filter cartridge with motor protection filter and foam
filter
9 Handle
10 On/off switch
11 Charging cable
12 Upholstery nozzle*
13 Crevice nozzle*
14 Professional upholstery nozzle*
15 Professional crevice nozzle*
16 Carrying strap*
17 Accessory adapter*
18 Flexible hose with handle*
Before using your appliance for the first
time
Fig.
1
Carefully plug the handle onto the main housing and
lock into place.
To release the handle, press the release button and
carefully lift the handle upwards to remove it.
Fig.
2
Plug the hand vacuum cleaner into the floor tool and
lock into place.
To release the floor tool, press the release button
and pull the hand vacuum cleaner out of the tool.
Charging
!
Caution: Before using the vacuum cleaner for the
first time, the batteries must be charged for at least
6 hours.
Fig.
3
To charge the vacuum cleaner, place it near to a so-
cket. The appliance can be left standing anywhere in
the room.
Fig.
7
Plug the charging cable into the connection at the
rear of the appliance.
Plug the charging cable plug into the socket.
The charging indicator flashes during the charging
process.
Once the battery is fully charged, the charging indi-
cator lights up in blue and no longer flashes.
It is normal for the charging cable and hand vacuum
cleaner to become hot and not a cause for concern.
Battery charging status indicator
Fig.
4*
The battery charging status indicator for the appliance
corresponds to one of the two following variants:
a) The indicator shows the charging status of the battery.
Once the battery is fully charged, the indicator lights
up in blue.
When the indicator flashes, the battery must be re-
charged.
b) The indicator LEDs show the charging status of the
battery.
Battery fully charged
Battery semi-charged
Battery low
When the final LED flashes, the battery must be re-
charged.
Vacuuming
Fig.
5
Move the on/off button in the direction of the arrow.
Controlling the suction level
Fig.
6
To change the suction power, slide the on/off switch to
the desired position:
Power level 1 1
Vacuuming without the electric brush switched on.
For simple cleaning tasks on hard floors and particu-
larly low operating noise.
The appliance achieves the maximum run time at
this level.
en
* Depending on model
