![Samsung PS42B430P [17/63] Picture options](/views2/1028111/page17/bg11.png)
English - 18
Picture Options
❑
Colour Tone →Cool / Normal / Warm1 / Warm2
You can select the most comfortable colour tone to your eyes.
The adjusted values are stored according to the selected
N Picture mode.
Warm1
N or Warm2 is only activated when the picture mode is Movie.
Size
You can select the picture size which best corresponds to your viewing requirements.
Auto Wide • : Sets the picture in Auto Wide format.
16:9 • : Sets the picture to the 16:9 aspect ratio.
Wide Zoom • : Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture
vertically.
Zoom • : Stretches the 16:9 aspect ratio picture vertical
4:3 • : Sets the picture to the 4:3 aspect ratio.
Screen Fit • : Displays the full native HD signal that cannot be viewed using a normal TV.
The picture size options may vary depending on the input source.
N
The items available may differ depending on the selected mode. N
Settings can be adjusted and stored for each external device you have connected to an input of the TV. N
Temporary image retention may occur when viewing a static image on the set for more than two hours. N
Wide Zoom N : Press the ► button to select Position, then press the ENTER
E
button.
Press the ▲ or ▼ button to move the screen up / down. Then press the ENTER
E
button.
Zoom
N : Press the ► button to select Position, then press the ENTER
E
button. Press the ▲ or ▼ button to move the picture
up and down. Then press the ENTER
E
button. Press the ► button to select Size, then press the ENTER
E
button.
Press the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the ENTER
E
button.
After selecting
N Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing
the ◄ or ►button. Use the ▲, ▼, ◄ or ► button to move the picture.
Reset
N : Press the ◄ or ► button to select Reset, then press the ENTER
E
button. You can initialize the setting.
If you use the
N Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the overscan
function.
Screen Mode
When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS
(Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is
intended for users to select it.
16:9 • : Sets the picture to the 16:9 aspect ratio.
Wide Zoom • : Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture
vertically.
Zoom • : Stretches the 16:9 aspect ratio picture vertically.
4:3 • : Selects the screen mode as 4:3
This function is available in
N
Auto Wide mode.
This function is not available in,
N
Component or HDMI mode.
Digital NR →Off / Low / Medium / High / Auto
If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static
and ghosting that may appear on the screen.
When the signal is weak, select one of the other options until the best picture is displayed.
N
HDMI Black Level
→Normal / Low
You can directly select the black level on the screen to adjust the screen depth.
This function is active only when the external input connects to HDMI (RGB signals).
N
Continued...
Tint (G/R) : G50/R50
Advanced Settings
PictureOptions ►
Picture Reset
BN68-02353F-Eng-1.indd 18 2009-06-30 �� 9:30:24
