Sony SVD-1121X9R/B Gun/Me [2/2] Русский
![Sony SVD-1121X9R/B Gun/Me [2/2] Русский](/views2/1080694/page2/bg2.png)
Quick
Start
Guide
Please read this manual and
Safety Regulations carefully
before using the product.
Keep them in a safe place.
Initial Setup
1
Check supplied items
2
Connect AC adapter
3
Turn on your
VAIO computer
4
Raise LCD screen
5
Connect to the
Internet
AC adapter
Power cord
Digitizer stylus
1
2
Extended battery pack
2
7
Start VAIO Care
8
Use Microsoft account
Parts and Controls
Plug the power cord and the AC adapter into
an AC outlet and the computer.
Be sure to connect the AC adapter to your
computer when using it for the first few times
to ensure the battery becomes fully charged.
Press and hold down the power button until
the power indicator light turns on.
The startup process will take a few minutes.
No action is required until the setup window
appears.
Grasp the top center edge of the LCD screen
and raise it to use the keyboard.
Connect to the Internet to automatically
activate Windows.
Wired connection
Connect your computer and router with a
LAN cable.
Wi-Fi® (Wireless LAN) connection
1
Open the charms by pointing to the top
right corner of the screen, then move the
pointer down and click the
Settings
charm.
2
Click (the network icon).
3
Select the desired network (SSID) and click
Connect.
For details on the security key and other
settings, refer to the manual of the network
device or the information from your Internet
service provider.
Sign in to Windows with a Microsoft account
so that you can use and download apps
from Windows Store.
1
Open the charms by pointing to the top
right corner of the screen, then move the
pointer down and click the
Settings
charm.
2
Click Change PC settings, Users, and
Switch to a Microsoft account.
3
Follow the on-screen instructions.
While the computer is on, press the ASSIST
button to start VAIO Care, then complete
the following steps by clicking the items in
the right pane.
Use VAIO Update
Click VAIO Software.
To use Windows Update, click the
Search charm and Settings, then search
Windows Update.
Create your Recovery Media
Click Advanced Tools.
Recovery Media are not supplied with your
computer. Refer to the supplied Recovery,
Backup and Troubleshooting Guide
before creating the Recovery Media.
Register your computer
Click About your VAIO.
1 The digitizer stylus is available for pen-
based input. Refer to the on-screen User
Guide for detailed information on how to
use the stylus.
2 Not supplied with all models. Availability
depends on your computer’s specifications.
Features and specifications may vary and are
subject to change without notice.
Personal Computer
VAIO Duo 11 SVD112
Support website
http://www.sony-europe.com/support
6
Locate User Guide
An introduction of the User Guide is
available on your computer. Update to the
complete guide online by following the
steps below.
1
Open the charms by pointing to the top
right corner of the screen, then move the
pointer down and click the
Search
charm.
2
Click Apps and enter “VAIO Manual” in the
search box.
3
Click VAIO Manual in the Apps list.
Русский
Care and Handling Tips
Computer Handling
Do not exert pressure on your computer,
especially the LCD/touch screen or the AC
adapter cable.
Ventilation
Place your computer on hard surfaces such
as a desk or table. Proper air circulation
around vents is important to prevent
overheating.
Liquid Damage
Protect your computer from contact with
liquids.
D
A
C
B
G
HE F
A
Built-in front camera /
indicator
Ambient light sensor
LCD screen / touch screen
D
Monitor port
Media access indicator
“Memory Stick Duo” /
SD memory card
combined slot
Headphones jack
Built-in microphone
B
Windows button
Optical Trackpad
Left button
Center button
Right button
E
Built-in speaker
VOL (Volume) buttons
Rotation lock button
ASSIST button Starts VAIO Care while your computer is on -
easily tune-up and self support the computer.
H (Bottom)
Battery off button
Extended battery pack
connector
Tilt feet
Touch mark
Built-in rear camera /
indicator
F
Power indicator
Charge indicator
Disc drive indicator
WIRELESS indicator
Built-in speaker
G
USB port x 2 (Compliant
with the USB 3.0 standard.
The port with the mark
supports USB charging.)
HDMI output port
Power button
On selected models only.
C (Back)
DC IN port
LAN port
