5
Instruction manual
5
will be shown on the screen.
• To switch off the player, hold the
FUNCTION button for 2 seconds.
General USB/SD/MMC notes
• This unit is equipped with a USB port
that can read and play MP3 files stored on a
standard USB flash drive (compatible with USB
version 2.0) up to 32 GB.
• This unit is also equipped with an SD/
MMC card socket that can accept and play
MP3 files stored on standard SD/MMC cards
up to 32 GB.
Always switch off the unit or change
mode to another one before removing a
USB flash drive or SD/MMC card, to prevent
damage to your USB device or memory card.
Note: Although this product is fully
compatible with USB 2.0 and SD/MMC card
standard formats, a small percentage of USB
flash drives and SD/MMC cards might not be
readable, due to those device manufacturers’
non-compliance with the full (official) USB and
SD/MMC card standards.
• FAT32 file system is supported by USB
and SD/MMC of this unit.
According to the USB 1.1/2.0 Standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.
Warning: usage of external USB drives
containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.
Alarm operation
Alarm mode
• In clock mode, press the ALARM button to
activate the alarm mode.
• In the alarm mode press and hold
the ALARM button to set the alarm time.
Repeatedly press the ALARM button to set
alarm parameters in a following sequence:
hours => minutes => alarm signal (Off/bb/FM/
USB/SD). The selected parameter will blink
meaning readiness for adjustment.
• Press SKIP UP to adjust the parameter up.
Press SKIP DN to adjust the parameter down.
• If no button is pressed within 10 seconds
after a parameter is selected, the unit will
automatically return to clock mode.
Alarm ringing
• To use radio as alarm sound, enable radio
mode, the last played station will be displayed
and used as the alarm.
• If radio was not set as an alarm signal,
then the unit will beep periodically.
• To use MP3 as alarm sound, insert a USB
drive or SD card, then select USB or SD/MMC
mode.
Do not select USB/SD as alarm signal
if a USB or memory card is not connected,
otherwise the alarm will not work.
• After setting the alarm, press the ALARM
button to exit to clock mode. The ALARM mode
is now on.
• When the alarm goes off press any button
(except the SNOOZE button) to stop the alarm.
Pushing the SNOOZE button will prolong the
alarm for 5 more minutes.
