Connect adapter to flat panel
Conecte el adaptador al monitor
Connectez l'adaptateur au moniteur
Befestigen Sie den Adapter am Bildschirm
Sluit de adapter aan op de monitor
Collegare l'adattatore allo schermo
Podłącz adapter do monitora
Připojte adaptér k monitoru
Csatlakoztassa az adaptert a monitorhoz.
Συνδέστε τον προσαρμογέα στην οθόνη
Ligar o adaptador ao monitor
Tilslut adapteren til skærmen
Kiinnitä sovitin näyttöön
Koppla adapter till bildskärm
Conectaţi adaptorul la monitor
Свържете адаптера към монитора
Ühendage adapter ekraaniga
Savienojiet savienotājelementu ar monitoru
Prijunkite adapterį prie monitoriaus
Adapter pritrdite na monitor
Pripojte adaptér k monitoru
Подключите адаптер к монитору
Adaptörü monitöre bağlayın
Koble adapteren til skjermen
بﺎﻗﺮﻤﻟﺎﺑ ﺊﻳﺎﻬﻤﻟا ﻞﺻو
将附件连接到显示器
アダプタをモニタに取り付けます。
4
WARNING! PLEASE SELECT THE PROPER SCREW LENGTH FOR YOUR FLAT PANEL
BY HAND TIGHTENING TO CHECK YOUR FLAT PANELS THREAD DEPTH.
10mm
M-I M-J
M-I
15mm 20mm 25mm 30mm
M-A
M-B
M-C
M-D
M-E
M-F
M-G
M-H
M-J
M-I
M-L
M-K
M-J
M-I
M-L
M-K
m4/m5
m6/m8
m4/m5
m6/m8
5
2
2
