Hotpoint-Ariston ARTXF 149 [5/60] How to open and to close the drum
![Hotpoint-Ariston ARTXD 129 [5/60] How to open and to close the drum](/views2/1029065/page5/bg5.png)
5
GB
Fig. 1
Fig. 2
Fig. 3
Fig. 4
A) Opening (Fig. 1):
Lift the external lid and open it completely.
B) Opening the drum (Soft opening):
With one finger, push the button indicated in fig. 2
and the drum will open delicately.
C) Loading the washing machine (Fig. 3).
D) Shutting (Fig. 4):
- close the drum fully by first shutting the front
door followed by the rear one;
- then ensure the hooks on the front door are
perfectly housed within the seat of the rear door;
- after the hooks have clicked into position, press
both doors lightly downwards to make sure they
do not come loose;
- finally shut the external lid.
E) Drum End Stop (Fig. 2):
Once the wash cycle has been completed, the drum will
position itself with doors facing upward for ease pf opening.
Starting a wash cycle
1. Turn the washing machine on by pressing the
ON/OFF button. All the indicator lights will turn on for a
few seconds, then only the indicator lights relative to the
selected programme settings will remain lit and the START/
PAUSE indicator light will flash.
2. Load the laundry, close the door and the lid.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see “Personalisation”).
5. Set the spin speed (see “Personalisation”).
6. Measure out the detergent and washing additives (see
“Detergents and laundry”).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/PAUSE
button and the corresponding indicator light will remain lit
in a fixed manner, in green.
To cancel the set wash cycle, pause the machine by pres-
sing the START/PAUSE button and select a new cycle.
9. At the end of the wash cycle the indicator light will
switch on. The LID LOCKED indicator light will switch off,
indicating that the door may be opened. Take out your
laundry and leave the appliance door ajar to make sure the
drum dries completely.
Switch the washing machine off by pressing the ON/OFF
button.
Temperature indicator light
When a temperature value is selected, the cor-
responding indicator light will illuminate.
Spin indicator light
When a spin value is selected, the correspon-
ding indicator light will illuminate.
Control panel lock indicator light
To activate the control panel lock, press and hold the
button for approximately 2 seconds. When the indicator
light is illuminated, the control panel is locked. This means
it is possible to prevent wash cycles from being modified
accidentally, especially where there are children in the home.
To deactivate the control panel lock, press and hold the
button for approximately 2 seconds.
Lid locked indicator light
If this indicator light is on, the appliance door is locked to prevent it
from being opened accidentally; to avoid any damage, wait for the
indicator light to switch off (it will take about three minutes) before
you open the appliance door.
N.B. If the DELAY TIMER function is activated, the door can-
not be opened; pause the machine by pressing the START/
PAUSE button if you wish to open it.
! If the START/PAUSE indicator light (orange) flashes rapidly
at the same time as the function indicator light, this indicates
a problem has occurred (see “Troubleshooting”).
How to open and to close the drum
