Siemens SF64T355 [8/28] Rinse aid
![Siemens SF64T355 [8/28] Rinse aid](/views2/1029094/page8/bg8.png)
en
8
As soon as the rinse-aid refill
indicator ` is lit on the fascia, there
is still a rinse-aid reserve of 1–2 rinsing
processes. Refill with rinse aid.
The rinse aid is required for stain-free
utensils and clear glasses. Use only rinse
aid for domestic dishwashers.
Combined detergents with rinse-aid
component may be used up to a water
hardness of 21° dH (37° fH, 26° Clarke,
3.7 mmol/l) only. If the water hardness
is over 21° dH, rinse aid must be used.
– Open the cover on the rinse-aid
dispenser 1j. To do this, press
the mark (1) on the cover
and simultaneously lift
the cover on the control plate (2).
– Carefully pour in the rinse aid to just
below the edge of the filler opening.
– Close cover until it clicks shut.
– To prevent excessive foam formation
during the next rinse cycle, remove any
rinse aid which has run over with
acloth.
Setting amount of rinse aid
The rinse aid dispensing rate can be
adjusted steplessly. The clear rinse
controller was set to 4 at the factory.
Do not change the position of the rinse aid
control unless there are streaks (rotate
towards –) or water stains (rotate towards
+) on the utensils.
Switching the rinse aid refill
indicator off or on
If the rinse-aid refill indicator `
is impaired (e. g. when using combined
detergents containing rinse aid
component), it can be switched off.
To change the setting:
– Keep pressing the timer programming
button 8 and press main switch (
until the digital display @ illuminates.
– Release buttons. On the digital display
@ ‚ is indicated (rinse-aid refill
indicator on).
– By pressing the timer programming
button 8, you can switch the rinse-
aid indicator off ‹ or on ‚.
– Switch off the main switch (;
the chosen setting has now been
stored.
Rinse aid %
5LQVHDLG
FRQWUROOHU
