AKAI MP 1200RC part list
LOCATION DESCRIPTION SPECIFICATION QTY.
MAIN BOARD PCB
L
OCATION DESCRIPTION SPECIFICATION QTY. PT_NR
SKON-II
MAIN PCB
PCB BOARD
SY-R200 MAIN PCB 1
115-
SYR20035-1
J3 FM MODUEL TEA5767 1
105-
*TEA5767-1
U1 IC ATJ2805
105-
*ATJ2805-1
U5 IC
K9F5608UOM-YCBO
FLASH(128MBit)
1
105-
K9F5608U-1
C6-7 CERAMIC CAP. 15PF (+/- 2PF 50V SMD 0402) 2
102-
61506207-0
C2 CERAMIC CAP. 100PF (+/-5% 16V 0402) 1
102-
61016207-0
C20 CERAMIC CAP. 470PF (+/-10% 50V SMD 0402) 1
102-
64716307-0
C3 CERAMIC CAP. 1000PF (+/-10%50V SMD 0402) 1
102-
61026307-0
C21-23 CERAMIC CAP. 0.01UF (+/-10% 50V SMD 0402) 3
102-
61036307-0
C9 C13 C17
C25
CERAMIC CAP. 0.1UF (+/-20%50V SMD 0402) 4
102-
61046307-0
C1 C4-5 C10-
12 C15-16
C19 C24
CERAMIC CAP. 0.22UF (+/-20% 50V SMD 0402) 11
102-
62246307-0
C14 CERAMIC CAP. 0.47UF (+/-20% 50V SMD 0402) 1
102-
64746307-0
R11 CHIP RESISTOR 0 ohm +/-5% 1/16w SMD 0402 1
101-
40000158-0
R3 CHIP RESISTOR 4R7 ohm +/-5% 1/16w SMD 0402 1
101-
40470158-0
R13-14 CHIP RESISTOR 20 ohm +/-5%1/16w SMD 0402 2
101-
42000158-0
R7-8 CHIP RESISTOR 24 ohm +/-5% 1/16w SMD 0402 2
101-
42400158-0
R12 CHIP RESISTOR 2K2 ohm +/-5% 1/16w SMD 0402 1
101-
42220158-0
R9-10 CHIP RESISTOR 47K ohm +/-5%1/16w SMD 0402 2
101-
44730158-0
R15-16 R22
R24-26
CHIP RESISTOR 51K ohm +/-5% 1/16w SMD 0402 6
101-
45130158-0
R1 CHIP RESISTOR 100K ohm +/-5% 1/16w SMD 0402 1
101-
41040158-0
R2 CHIP RESISTOR
150K ohm +/-5% 1/16w SMD
0402
1
101-
41540158-0
CE1-2 CE4-5
CE7-8 CE3
CHIP TANTALUM CAP.
47UF/6.3V +/-20% (3528) 7
102-
44761410-0
CE6
CHIP TANTALUM CAP.
100UF/6.3V +/-20% (3528) 1
102-
41071410-0
CE10-11 CE9
CHIP TANTALUM CAP.
220UF/6.3V +/-20% (3528) 3
102-
42271410-0
D1 DIODE 1N4148 1
104-
1IN41480-1
U2 IC XC6206P152M SOT23 1
105-
XC6206P1-1
