Sony SLV-KF295SV [7/28] Additional connections
![Sony SLV-KF295SV [7/28] Additional connections](/views2/1029327/page7/bg7.png)
Getting Started
7
SLV-KF295SV/XF245SV 3-858-368-11 (1)
Getting Started
Additional connections
To a TV that has phono type
audio/video input jacks
This additional connection
improves picture and sound quality.
Connect the TV as shown on the
right.
To a stereo system
You can improve sound quality by
connecting a stereo system as
shown on the right.
TV
This unit
Audio/video cable (supplied)
AUDIO VIDEO
LINE IN
LINE OUT
IN
VIDEO
AUDIO
This unit
Stereo system
AUDIO VIDEO
LINE IN
LINE OUT
AUX IN
Audio cable (not supplied)
