TO ASSEMBLE

1. FIRST PUT THE UNIT UPSIDE DOWN.

2. PLACE THE WНEEL BRACKETS IN THE LAST PANEL ON EITHER END OF THE UNIT.

FACE WHEELS UP TOWARDS YOU AND ATTACH BY MEANS OF U BOLTS AND WING

NUTS SUPPLIED.

3. SLIDE U BOLT UNDER HEATER FRAME AND THEN ATTACH TO WHEEL BRACKETS.

TO USE

1. Insert the plug into the suitable wall outlet.

1) Never use the unit in place where is not even, make sure there is nothing flammable or

easy deform object within 1 meter (36 inches).

2) Insert the plug after setting the thermostat to "OFF" position and setting the power

selected switches to “OFF" position.

3) Do not cover the unit.

4) The heater is suitable for operation on an A.C. electricity supply having the same volt

age as that show on it's rating label.

2. When radiator is connected to the mains, turn the thermostat control knob in a clock

wise direction to the MAX position and push on both switches:

 Switch marked I: is for low heat

 Switch marked II: is for medium heat.

 Both switches depressed together: are for high heat.

3. Turbo function

Press the switch to "ON" position, the fan heater begins to work separately and used as

a fan heater. The temperature in the room will rise rapidly.

TEMPERATURE REGULATION

When the desired room temperature has been reached, turn the thermostat control knob

back, the switch pilot lights remain on, as provided for in European standarts. The tem

perature will remain the same, controlled by the thermostat.

If the weather allows, it is possible to choose a lower heat setting by switching off one of

the switches for a more economical use of electricity.

CLEANING AND MAINTENANCE

1) The electric heater should be cleaned regularly to wipe out the dust in the surface of

flanges. As this may result the radiating efficient.

2) Disconnect electricity supply and allow radiator to cool, wipe out with a soft damp

cloth. Do not use detergent or abrasives.

3) Do not scrap the surfaces of flanges with sharp hard tools, to avoid surfaces getting

rusty, because of damage of the paint coat.
