25
Getting Started
Getting Started
1 Follow steps 1 and 2 in “Using the Auto Clock Set feature.”
The AUTO CLOCK SET menu is displayed.
2 Press CURSOR ?// to set FULL AUTO
to NO.
3 Press CURSOR >/. to move the cursor (z) to
the item you want to set, then change the
setting with the CURSOR ?//.
• For CLOCK SET CH
Leave CLOCK SET CH to “– – –” to
have the VCR automatically search for a
channel that carries a time signal.
Press the number buttons to search a
channel that carries a time signal. Use
this option if you know of a channel that
carries a time signal. Most PBS member
stations broadcast a time signal. For the
fastest response, select your local PBS
station.
AUTO CLOCK SET
FULL AUTO
•
CH 1[
YES NO
CLOCK SET 22 ]
TIME ZONE
DAYLIGHT SAVING
AUTO[]
AUTO[]
SELECT
SET
END
:[ ]
:
]: [ EXECUTE
[ 0–9 ] keys
MENU
CURSOR
EXECUTE
Number
buttons
•CURSOR
•CURSOR
continued
If the clock is not activated
AUTO CLOCK SET
FULL AUTO
•
CH –[
YES NO
CLOCK SET –– ]
TIME ZONE
DAYLIGHT SAVING
AUTO[]
AUTO[]
SELECT
SET
END
:[ ]
:[
]: [ EXECUTE
]
