Sony ICF-C263 [2/2] Adjust the volume using volume
![Sony ICF-C263 [2/2] Adjust the volume using volume](/views2/1029948/page2/bg2.png)
T
U
N
E
/
T
I
M
E
S
E
T
N
A
P
B
R
I
G
H
T
N
E
S
S
A
L
A
R
M
M
O
D
E
A
L
A
R
M
S
E
T
C
L
O
C
K
S
E
T
P
R
E
S
E
T
T
U
N
I
N
G
S
L
E
E
P
S
T
A
T
I
O
N
S
E
L
E
C
T
/
P
R
E
S
E
T
RADIO ON
/BAND
OFF
ALARM
RESET
SNOOZE
/SLEEP OFF
1
2
3
4
5
+
-
B
A
Setting the Clock
1 Plug in the unit.
“AM 12:00” flashes on the display.
2 Press CLOCK SET for a few seconds
until a beep sounds.
The hour starts to flash on the display.
3 Press TUNE/TIME SET + or – until the
correct hour appears.
To set the current time rapidly, hold down TUNE/
TIME SET + or –.
4 Press CLOCK SET once.
The minute starts flashing.
5 Repeat steps 3 and 4 to set the minute.
Two short beeps sound, and the counting of the
seconds starts.
If you quit during the clock setting, after about 65
seconds the previous display will return.
To set the current time from zero seconds, press
CLOCK SET with the time signal in step 5.
Setting the
Brightness of the
Backlight
Press BRIGHTNESS to select high, middle or low
for the display according to your preferences.
Changing AM
Channel Step
The AM channel step differs depending on area.
The channel step of this unit is factory-set to 9 kHz or
10 kHz to change the setting as shown below to be
able to listen to the radio.
Area Channel step
North and South America 10 kHz
Other countries/regions 9 kHz
1 Press OFF•ALARM RESET to turn off
the power.
2 Press PRESET TUNING 1 and
SLEEP at the same time for more than 5
seconds.
Two short beeps will sound, and the AM channel
step will be changed. If you proceed to step 2, the
channel step will change again.
Notes
•When the AM channel step is changed, the preset
stations for AM will be initialized.
•When the AM channel step is changed, the FM
channel step also will be changed.
The PRESET TUNING 3
button has a tactile dot.
VOLUME
There is a tactile dot beside
volume to show the direction
to turn up the volume.
AC power cord
FM wire antenna
Playing the Radio
—Manual Tuning
1 Press RADIO ON/BAND to turn on the
radio.
The display shows the band and frequency for a
few seconds and then changes back to the current
time.
2 Press RADIO ON/BAND to select the
band.
Each press changes the band as follows:
AM
FM1
FM2
When using FM1 or FM2 preset mode, you may
listen to the radio on either mode (See “Presetting
Your Favourite Station”).
3 Press TUNE/TIME SET + or – to tune
into the desired station.
Two short beeps sound when the minimum
frequency of each band is received during tuning.
4 Adjust volume using VOLUME.
To check the station being received
Press TUNE/TIME SET + or – lightly. The display
shows the band and frequency for a few seconds and
then returns to the previous display.
To turn off the radio, press OFF•ALARM RESET.
Improving the
Reception
FM: Extend the FM wire antenna fully to increase
reception sensitivity.
AM: Rotate the unit horizontally for optimum
reception. A ferrite bar is built into the unit.
Do not operate the unit over a steel desk or metal
surface, as this may lead to interference of reception.
Presetting Your
Favourite Station
—Preset Tuning
You can preset up to 10 stations in FM (5 stations in
FM1, 5 stations in FM2), and 5 stations in AM.
Presetting a Station
1 Follow steps 1 to 4 in “Playing the Radio”
and manually tune into the station you wish
to preset.
2 Hold down the preset button you wish to
preset for more than 2 seconds.
Example: Display window when you set FM
90 MHz in the PRESET TUNING 2
button for FM2.
The preset number “2” and “ ” flash in the
display.
Two beeps sound, and “2” and “
” stop
flashing.
To preset another station, repeat these steps.
To change the preset station, tune into the desired
station and hold down the PRESET TUNING 1
to 5 button. The new station will replace the
previous station on the preset button.
Tuning into a Preset Station
1 Press RADIO ON/BAND to turn on the
radio.
2 Press RADIO ON/BAND to select the
band.
3 Press the desired preset button.
4 Adjust the volume using VOLUME.
After a few seconds, the display will return to the
current time but the preset button number will
remain.
Note
Holding down the desired PRESET TUNING button
for more than a few seconds in step 3 will replace the
previous station on the PRESET TUNING button
with the station you tuned into.
Setting the Alarm
This clock radio is equipped with 2 alarm modes—
radio and buzzer. Before setting the alarm, make sure
to set the clock (see “Setting the Clock”).
To Set the Alarm Time
1 Press ALARM SET A or B for a few
seconds.
After one beep, “RADIO” or “BUZZER” and the
hour will flash on the display.
2 Press TUNE/TIME SET + or – until the
desired hour appears.
To set the hour rapidly, hold down TUNE/TIME
SET + or –.
3 Press ALARM SET A or B.
After one beep, the minutes will flash.
4 Repeat step 2 to set the minutes and press
ALARM SET A or B.
After one beep, the alarm mode is entered.
5 Press TUNE/TIME SET + or – until the
desired alarm indicator flashes.
You can choose one mode among “RADIO” and
“BUZZER.” Set the alarm mode as follows:
– RADIO: see “A Setting the Radio Alarm.”
– BUZZER: see “B Setting the Buzzer Alarm.”
A Setting the Radio Alarm
For the radio alarm, the station you specified as the
wake-up station is played.
1 Perform steps 1 to 5 in “To set the Alarm
Time”.
2 Press TUNE/TIME SET + or – to select
“RADIO” alarm mode.
3 Press ALARM SET A or B to select the
desired wake-up station.
After one beep, “WAKE UP” appears and the
preset number flashes on the display.
4 Press TUNE/TIME SET + or – to select
the desired wake-up station.
Preset number changes in the order as follows:
P
-
AM P1 to 5
FM1 P1 to 5FM2 P1 to 5
“P–” is the last received station.
You can directly select the desired wake-up
station by pressing RADIO ON/BAND or the
PRESET TUNING button while the indication
“P–” is not displayed.
5 Press ALARM SET A or B.
Two short beeps will confirm the setting.
B Setting the Buzzer Alarm
1 Perform steps 1 to 5 in “To set the Alarm
Time”.
2 Press TUNE/TIME SET + or – to select
“BUZZER” alarm mode.
3 Press ALARM SET A or B.
Two short beeps will confirm the setting.
Setting the Alarm Mode
Before setting the alarm mode, be sure to set the alarm
time (See “Setting the Alarm”).
Press ALARM MODE repeatedly until the desired
mode is selected.
Each press of ALARM MODE changes the indication
on the display as follows:
No alarm
Indication
or or
or
or
If the same alarm time is set for both radio and buzzer
alarm (ALARM A and B), the radio alarm (ALARM
A) takes priority.
To Doze for a Few More
Minutes
Press SNOOZE/SLEEP OFF.
The radio or buzzer turns off but will automatically
come on again after about 10 minutes. Every time you
press SNOOZE/SLEEP OFF, the snooze time
changes as follows:
10
20
30 40 50 60
The maximum length of the snooze time is 60
minutes.
The display shows the snooze time for a few seconds
and returns to show the current time. When you press
SNOOZE/SLEEP OFF after the current time
appears, the snooze time starts from 10 minutes again.
The alarm setting indicator keeps flashing the whole
time.
To Stop the Alarm
Press OFF•ALARM RESET to turn off the alarm.
The alarm will come on again at the same time the
next day.
To Deactive the Alarm
Press ALARM MODE repeatedly so that “ ”
or “
” and “ ” or “ ” go
off.
Using the NAP
Timer (Count Down
Timer)
The NAP timer sounds the buzzer after a preset time
duration.
Press NAP repeatedly until the desired minutes is
displayed.
Every press changes the display as follows:
OFF
(current time)
10
20
90
120
60
30
Two short beeps sound when the display returns to
“10”.
The NAP indicator turns on, “ ” and the NAP
time are displayed for a few seconds.
NAP timer starts counting down the NAP time.
When selected NAP time has passed, the beep sound
comes on, and the NAP indicator and “
” on the
display flash.
To Stop NAP Timer
Press NAP or OFF•ALARM RESET to turn off the
buzzer.
To Deactive NAP Timer
Press NAP. The NAP indicator and “ ” go off.
Setting the Sleep
Timer
You can enjoy falling asleep to the radio using the
built-in sleep timer that turns off the radio automati-
cally after a preset duration.
Press SLEEP.
The radio turns on. You can set the sleep timer to
duration of 90, 60, 30, or 15 minutes. Every press
changes the display as follows:
OFF
90
60
30
15
Two short beeps sound when the display returns to
“90”.
“ ” will appear in the display when the duration
time is set.
The radio will play for the time you set, then shut off.
To turn off the radio before the preset time
Press SNOOZE/SLEEP OFF or OFF•ALARM
RESET.
To Use Both Sleep Timer
and Alarm
You can fall asleep to the radio and also be awakened
by the radio or buzzer alarm at the preset time.
1 Set the alarm (See “Setting the Alarm”) .
2 Set the sleep timer (See “Setting the Sleep
Timer”).
Содержание
- Antenna discharge unit nec section 810 20 grounding conductors nec section 810 20 1
- Antenna lead in wire 1
- Do not attempt to service the appliance yourself as opening or removing covers may expose you to dangerous voltage or other hazards refer all servicing to qualified service personnel 1
- Do not overload wall outlets extension cords or convenience receptacles beyond their capacity since this can result in fire or electric shock 1
- Do not place the appliance near or over a radiator or heat register or where it is exposed to direct sunlight 1
- Do not place the appliance on an unstable cart stand tripod bracket or table the appliance may fall causing serious injury to a child or an adult and serious damage to the appliance use only a cart stand tripod bracket or table recommended by sony an appliance and cart combination should be moved with care quick stops excessive force and uneven surfaces may cause the appliance and cart combination to overturn 1
- Do not use attachments not recommended by sony as they may cause hazards 1
- Do not use powerline operated appliances near water for example near a bathtub washbowl kitchen sink or laundry tub in a wet basement or near a swimming pool etc 1
- Electric service equipment ground clamps 1
- Features 1
- Fm am pll synthesized clock radio 1
- For added protection for this appliance during a lightning storm or when it is left unattended and unused for long periods of time unplug it from the wall outlet and disconnect the antenna or cable system this will prevent damage to the appliance due to lightning and powerline surges 1
- For your protection please read these safety instructions completely before operating the appliance and keep this manual for future reference carefully observe all warnings precautions and instructions on the appliance and in the operating instructions and adhere to them 1
- Ground clamps 1
- Icf c263 1
- If an outdoor antenna or cable system is installed follow the precautions below an outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits or where it can come in contact with such power lines or circuits when installing an outdoor antenna system extreme care should be taken to keep from contacting such power lines or circuits as contact with them is almost invariably fatal be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges section 810 of the national electrical code provides information with respect to proper grounding of the mast and supporting structure grounding of the lead in wire to an antenna discharge unit size of grounding conductors location of antenna discharge unit connection to grounding electrodes and requirements for the grounding electrode 1
- If your appliance can be mounted to a wall or ceiling mount it only as recommended by sony 1
- Important safeguards 1
- Nec national electrical code 1
- Never push objects of any kind into the appliance through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock never spill liquid of any kind on the appliance 1
- Power service grounding electrode system nec art 250 part h 1
- Precautions 1
- Route the power cord so that it is not likely to be walked on or pinched by items placed upon or against them paying particular attention to the plugs receptacles and the point where the cord exits from the appliance 1
- Specifications 1
- The slots and openings in the cabinet are provided for necessary ventilation to ensure reliable operation of the appliance and to protect it from overheating these slots and openings must never be blocked or covered never cover the slots and openings with a cloth or other materials never block the slots and openings by placing the appliance on a bed sofa rug or other similar surface never place the appliance in a confined space such as a bookcase or built in cabinet unless proper ventilation is provided 1
- This appliance is equipped with a polarized ac power cord plug a plug having one blade wider than the other or with a three wire grounding type plug a plug having a third pin for grounding follow the instructions below 1
- This appliance should be operated only from the type of power source indicated on the marking label if you are not sure of the type of electrical power supplied to your home consult your dealer or local power company for those appliances designed to operate from battery power or other sources refer to the operating instructions 1
- This plug will fit into the power outlet only one way this is a safety feature if you are unable to insert the plug fully into the outlet try reversing the plug if the plug should still fail to fit contact your electrician to have a suitable outlet installed do not defeat the safety purpose of the polarized plug by forcing it in 1
- This plug will only fit into a grounding type power outlet this is a safety feature if you are unable to insert the plug into the outlet contact your electrician to have a suitable outlet installed do not defeat the safety purpose of the grounding plug 1
- Troubleshooting 1
- Unplug the appliance from the wall outlet and refer servicing to qualified service personnel under the following conditions when the power cord or plug is damage or frayed if liquid has been spilled or objects have fallen into the appliance if the appliance has been exposed to rain or water the appliance does not appear to operate normally or exhibits a marked change in performance this indicates a need for service if the appliance does not operate normally when following the operating instructions adjust only those controls that are specified in the operating instructions improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the appliance to normal operation if the appliance has been subject to excessive shock by being dropped or the cabinet has been damaged 1
- Unplug the appliance from the wall outlet before cleaning or polishing it do not use liquid cleaners or aerosol cleaners use a cloth lightly dampened with water for cleaning the exterior of the appliance clean the appliance only as recommended by sony 1
- Unplug the power cord of the appliance from the outlet when left unused for a long period of time to disconnect the cord pull it out by grasping the plug never pull the plug out by the cord 1
- Upon completion of any service or repairs to the appliance ask the service technician to perform routine safety checks as specified by sony to determine that the appliance is in safe operating condition 1
- When replacement parts are required be sure the service technician has used replacement parts specified by sony that have the same characteristics as the original parts unauthorized substitutions may result in fire electric shock or other hazards 1
- 120 60 2
- 20 30 40 50 60 2
- A setting the radio alarm 2
- Ac power cord 2
- Adjust the volume using volume 2
- Adjust volume using volume 2
- Am fm1 fm2 2
- Am p1 to 5 2
- B setting the buzzer alarm 2
- Changing am channel step 2
- Fm wire antenna 2
- Fm1 p1 to 5 fm2 p1 to 5 2
- Follow steps 1 to 4 in playing the radio and manually tune into the station you wish to preset 2
- Hold down the preset button you wish to preset for more than 2 seconds 2
- Improving the reception 2
- Manual tuning 2
- Off 90 60 2
- Perform steps 1 to 5 in to set the alarm time 2
- Playing the radio 2
- Plug in the unit 2
- Preset tuning 2
- Presetting a station 2
- Presetting your favourite station 2
- Press alarm set a or b 2
- Press alarm set a or b for a few seconds 2
- Press alarm set a or b to select the desired wake up station 2
- Press clock set for a few seconds until a beep sounds 2
- Press clock set once 2
- Press off alarm reset to turn off the power 2
- Press preset tuning 1 and sleep at the same time for more than 5 seconds 2
- Press radio on band to select the band 2
- Press radio on band to turn on the radio 2
- Press the desired preset button 2
- Press tune time set or to select buzzer alarm mode 2
- Press tune time set or to select radio alarm mode 2
- Press tune time set or to select the desired wake up station 2
- Press tune time set or to tune into the desired station 2
- Press tune time set or until the correct hour appears 2
- Press tune time set or until the desired alarm indicator flashes 2
- Press tune time set or until the desired hour appears 2
- Repeat step 2 to set the minutes and press alarm set a or b 2
- Repeat steps 3 and 4 to set the minute 2
- Set the alarm see setting the alarm 2
- Set the sleep timer see setting the sleep timer 2
- Setting the alarm 2
- Setting the alarm mode 2
- Setting the brightness of the backlight 2
- Setting the clock 2
- Setting the sleep timer 2
- The preset tuning 3 button has a tactile dot 2
- To deactive nap timer 2
- To deactive the alarm 2
- To doze for a few more minutes 2
- To set the alarm time 2
- To stop nap timer 2
- To stop the alarm 2
- To use both sleep timer and alarm 2
- Tuning into a preset station 2
- Using the nap timer count down timer 2
- Volume there is a tactile dot beside volume to show the direction to turn up the volume 2
Похожие устройства
- Electrolux EWT1366HDW Инструкция по эксплуатации
- Leica TCR 307 Инструкция по эксплуатации
- Olympus C-1 Zoom Инструкция по эксплуатации
- Novex NFT-201 Инструкция по эксплуатации
- Bresser Science ADL-601P Инструкция по эксплуатации
- Sony ICF-C25MK2 Инструкция по эксплуатации
- Leica TCR 403 Инструкция по эксплуатации
- Bresser Junior 40x-1024x (без кейса) Инструкция по эксплуатации
- Novex NAN-02 Инструкция по эксплуатации
- Scarlett SC-151 Инструкция по эксплуатации
- Sony ICF-C233L Инструкция по эксплуатации
- Whirlpool AWS 61212 Инструкция по эксплуатации
- Leica TCR 405 Инструкция по эксплуатации
- Xoro HSD 2130 Инструкция по эксплуатации
- Novex NAN-101 Инструкция по эксплуатации
- Bresser Junior Argo Инструкция по эксплуатации
- Sony ICF-C218 Инструкция по эксплуатации
- Whirlpool AWS 61012 Инструкция по эксплуатации
- Zanussi IT 5660 Инструкция по эксплуатации
- Leica TCR 407 Инструкция по эксплуатации
