4
ENGLISH (Original instructions)
Explanation of general view
1-1. Red indicator
1-2. Button
1-3. Battery cartridge
2-1. Star marking
3-1. Lever
3-2. Stopper base
3-3. Label on feeder box
3-4. Fenestella
4-1. Stopper base
4-2. Casing
4-3. Adjusting knob
5-1. Switch trigger
6-1. Reversing switch lever
7-1. Casing
7-2. Thumb screw
8-1. Plane bearing
8-2. Dust cover
8-3. Bit
9-1. Feeder box
9-2. Screw strip
9-3. Screw guide
10-1. Driving position
12-1. Reverse button
14-1. Hook
16-1. Wall
16-2. Stopper base
17-1. Limit mark
18-1. Casing
18-2. Thumb screw
19-1. Front cover
19-2. Screws
20-1. Spring
20-2. Arm
20-3. Recessed part
21-1. Carbon brush cap
22-1. Hole
22-2. Carbon brush cap
SPECIFICATIONS
Model DFR540 DFR550 DFR750
Screw strip 4 x 25 - 55 mm 4 x 45 - 75 mm
No load speed (min
-1
) 4,000
Overall length 424 mm 464 mm
Net weight 2.0 kg 2.1 kg 2.1 kg
Rated voltage D.C. 14.4 V D.C. 18 V D.C. 18 V
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
ENE033-1
Intended use
The tool is intended for screw driving in wood, metal
and plastic.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Model DFR540
Sound pressure level (L
pA
) : 77 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Model DFR550
Sound pressure level (L
pA
) : 78 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Model DFR750
Sound pressure level (L
pA
) : 76 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode: screwdriving without impact
Vibration emission (a
h
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
ENG901-1
•
The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
