Makita DJV181Z [9/64] Maintenance

Fig.16

Tilt the base until the desired bevel angle is obtained.

The V-notch of the gear housing indicates the bevel

angle by graduations. Then tighten the bolt firmly to

secure the base.

Front flush cuts

Fig.17

Loosen the bolt on the back of the base with the hex

wrench and slide the base all the way back. Then

tighten the bolt to secure the base.

Cutouts

Cutouts can be made with either of two methods A or B.

A) Boring a starting hole:

Fig.18

• For internal cutouts without a lead-in cut from an

edge, pre-drill a starting hole 12 mm or more in

diameter. Insert the blade into this hole to start

your cut.

B) Plunge cutting:

Fig.19

• You need not bore a starting hole or make a lead-

in cut if you carefully do as follows.

1. Tilt the tool up on the front edge of the base with

the blade point positioned just above the

workpiece surface.

2. Apply pressure to the tool so that the front edge

of the base will not move when you switch on the

tool and gently lower the back end of the tool

slowly.

3. As the blade pierces the workpiece, slowly lower

the base of the tool down onto the workpiece

surface.

4. Complete the cut in the normal manner.

Finishing edges

Fig.20

To trim edges or make dimensional adjustments, run the

blade lightly along the cut edges.

Metal cutting

Always use a suitable coolant (cutting oil) when cutting

metal. Failure to do so will cause significant blade wear.

The underside of the workpiece can be greased instead

of using a coolant.

Rip fence set (optional accessory)

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before installing or

removing accessories.

1. Straight cuts

Fig.21

When repeatedly cutting widths of 160 mm or less, use

of the rip fence will assure fast, clean, straight cuts.

Fig.22

To install, insert the rip fence into the rectangular hole

on the side of the tool base with the fence guide facing

down. Slide the rip fence to the desired cutting width

position, then tighten the bolt to secure it.

2. Circular cuts

Fig.23

Fig.24

When cutting circles or arcs of 170 mm or less in

radius, install the rip fence as follows.

1. Insert the rip fence into the rectangular hole on

the side of the base with the fence guide facing

up. Insert the circular guide pin through either of

the two holes on the fence guide. Screw the

threaded knob onto the pin to secure the pin.

2. Now slide the rip fence to the desired cutting

radius, and tighten the bolt to secure it in place.

Then move the base all the way forward.

NOTE:

• Always use blades No. B-17, B-18, B-26 or B-27

when cutting circles or arcs.

Guide rail adapter set (optional accessory)

Fig.25

When cutting parallel and uniform width or cutting

straight, the use of the guide rail and the guide rail

adapter will assure the production of fast and clean cuts.

To install the guide rail adapter, insert the rule bar into

the square hole of the base as far as it goes. Secure the

bolt with the hex wrench securely.

Fig.26

Install the guide rail adapter on the rail of the guide rail.

Insert the rule bar into the square hole of the guide rail

adapter. Put the base to the side of the guide rail, and

secure the bolt securely.

Fig.27

CAUTION:

• Always use blades No. B-8, B-13, B-16, B-17 or

58 when using the guide rail and the guide rail

adapter.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to

perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or

the like. Discoloration, deformation or cracks may

result.

To maintain product SAFETY and RELIABILITY, repairs,

any other maintenance or adjustment should be

performed by Makita Authorized Service Centers,

always using Makita replacement parts.
