BINOCULARS

Do not subject the device to temperatures

exceeding 60° C!

List of Parts

B Centre axle

Ca Twist-up eyecups

Cb Rubber eyecups

D Dioptre adjustment

E Body of the binoculars

F Lens tube

G Central focussing wheel

H Eyepiece

I Objective lens

J Threaded tripod connection

1) Zoom lever

1! Magnication scale

1@ Image circle with correctly set eye distance

Eyepieces for spectacle wearers

Depending on the model, your binoculars are

equipped with either twist-up eyecups (2a) or

rubber eyecups (2b). Since there is a larger dis-

tance between the binocular eyepiece and the

pupil for those wearing glasses, both eyecup

varieties can be adjusted individually.

Twist-up Eyecups (2a)

Screw in the twist-up eyecups (2a) to use the

binoculars while wearing glasses. If you are

not wearing glasses, unscrew the eyecups to

achieve the required distance from the pupils.

Rubber Eyecups (2b)

To use the binoculars while wearing glasses,

turn the rubber eyecups (2b) towards the sides

and down. If you are not wearing glasses, leave

the eyecups in the upright position to achieve

the required distance from the pupils.

Adjusting the eyepiece distance

The distance between the eyes differs between

individuals. To achieve perfect interaction be-

tween your eyes and the eyepieces of your

binoculars set the angle at the centre of the bin-

oculars (1) so that you see a circular image (12).

Note this setting for later use.
