Intended use
Keep in mind that every type of bike is designed for a
specific use. Be sure to use your MERIDA bike only ac-
cording to its intended use, as it may otherwise not with-
stand the stress and could fail and cause an accident
with unforeseeable consequences! If you use your bike
for another than its intended purpose, the warranty will
become void.
Category 1: Road bikes, triathlon bikes, time trial
machines and cyclo-cross bikes
MERIDA road bikes
(a)
, MERIDA triathlon bikes and
MERIDA time trial machines
(b)
are intended to be used
on public roads and trails with tarred or paved surface.
MERIDA cyclo-cross bikes/road racing machines
(c)
are also suitable for off-road cycling on gravel field and
forest tracks, however, not for rough terrain. They are not
suitable for mountain bike use, namely for all mountain,
enduro, downhill, freeride and in bike parks.
Due to their design and fittings MERIDA road bikes,
MERIDA triathlon bikes, MERIDA time trial machines
and MERIDA cyclo-cross bikes are not suitable for be-
ing used on public roads. If you want to use them on
public roads, these bikes must be fitted with the pre-
scribed equipment. Observe the traffic rules when riding
on public roads. For more information see your compre-
hensive MERIDA user manual on the enclosed MERIDA
CD-ROM.
Category 1: MERIDA bikes of this category are designed
for riding on hard-surface roads where the wheels re-
main in permanent contact to the ground. In general,
these are MERIDA road racing bikes with racing bars or
straight handlebars, MERIDA triathlon or MERIDA time
trial machines. The rider’s maximum weight incl. bag-
gage and bike should not exceed 120 kg. Under certain
circumstances this permissible maximum weight can be
further limited by the component manufacturers’ recom-
mendations for use.
A
Due to their design and fittings MERIDA
road bikes, MERIDA triathlon bikes, MERIDA
time trial machines and MERIDA cyclo-cross
bikes/road racing machines are not suitable for being
used on public roads. If you want to use them on public
roads, these bikes must be fitted with the prescribed
equipment. Observe the traffic rules when riding on
public roads. For more information see your compre-
hensive MERIDA user manual on the enclosed MERIDA
CD-ROM.
Categories 0 and 1: City, trekking and kids’ bikes
MERIDA city, MERIDA trekking, MERIDA urban and
MERIDA kids’ bikes
(e)
are intended for hard-surface
roads, i.e. for tarred roads and bicycle lanes or gravel
field tracks. Observe the traffic rules when riding on pub-
lic roads. These MERIDA bikes are not suitable for off-
road and competitive use of any kind whatsoever.
G
MERIDA bikes of the cat-
egories 0, 1, 2 and 3 are
not suitable for stair rid-
ing, jumps, slides, stoppies, wheel-
ies, tricks etc.!
