WIRING AND BATTERY INFORMATION

eng 9

Wiring and Battery Information

WARNING

An operating or charging battery produces gas that can ignite and

explode, spraying out sulfuric acid, which can cause severe burns.

Ventilate the area around the battery and wear protective equipment

when handling or servicing batteries.

WARNING

Performing service or maintenance without first disconnecting the

battery can cause product damage, personal injury, or death due to

fire, explosion, electrical shock, or unexpected motor starting. Always

disconnect the battery cables from the battery before maintaining,

servicing, installing, or removing motor components.

Standard Practices and Procedures

When installing or removing this trolling motor, follow these guidelines:

• Disconnect the trolling motor from the trolling motor battery.

• Do not use the main engine battery to power the trolling motor.

Battery Recommendations

• Use a 12 volt, deep cycle marine battery.

• Install a 50 amp manual reset circuit breaker in line with the trolling

motor positive leads within 180 cm (72 in.) of the batteries.

• If extending the existing wire beyond the standard battery cable,

use 13 mm (6 gauge) battery cables.

Recommended MotorGuide Accessory Description Part Number

6 gauge battery cable and terminals with 50 amp manual reset

breaker

MM309922T

50 amp manual reset breaker MM5870
