www.timberk.com • Electric air conditioner

«SUPER» mode (TURBO)

When pressing the «TURBO» button on the remote control board, the

conditioner will start working in turbo mode – for maximum cooling (in cool

mode) or for maximum heating (in heat mode).

TIMER mode

Procedure of timing:

– If the conditioner is off, then press the “TIMER” button to activate the

automatic turning on. Pressing this button once again, set the time for

turning the conditioner on in the set time interval. To cancel the timer mode,

press the “TIMER” button once again.

–If the conditioner is working, then press the “TIMER” button to activate

the automatic turning off. Pressing this button once again, set the time for

turning the conditioner off in the set time interval. To cancel the timer mode,

press the “TIMER” button once again.

AUTO mode (SMART)

The auto mode is turned on and off with the use of the button “MODE” on

the remote control board.

1. While working in the AUTO mode, a microprocessor will automatically

select COOL, FAN, HEAT or DRY modes based on the difference between

actual and preset air temperature indoors.

2. If the AUTO mode does not provide comfort conditions, select the mode

manually. In automatic mode, depending on air temperature in the room,

the conditioner will select needed temperature parameters of its operation

in the following order:

7. OPERATING MODES

Temperature indoors Automatic mode sele ction Automatically maintained temperature

if <20° С then HEAT mode shall be turned on 23° С

if <20° С - 26° С then DRY mode shall be turned on 18° С

if <26° С

then COOL mode shall be turned on

23° С

ASmart mode allows changing threshold of switching from mode to mode.

During operation in Smart mode you see «-» on the display. Press keys

Temp +/-. «-» will change by +(-) 2. The range shift of this threshold

ASmart mode allows changing threshold of switching from mode to mode.

During operation in Smart mode you see «-» on the display. Press keys

Temp +/-. «-» will change by +(-) 2. The range shift of this threshold is within

-2...+2 of default temperatures.

NOTE:

If there is a difference between set and actual air

temperature in DRY mode, the conditioner will

automatically turn on in COOL or FAN modes.

NOTE:

After installing the batteries in the remote control for

a few seconds will alternately flashing heating and

cooling. To select the mode of the console «cooling

only» press any key on the remote control during

display cooling mode.

To select the operation mode of the remote control

«cooling-heating» press any key during the display of

the heating mode, or do not press any key to stop the

flashing indicator.

COOL, HEAT and FAN

1. Turn the conditioner on pressing the «ON/OFF» button.

2. Pressing the «MODE» button, select COOL, HEAT or FAN mode

manually.

3. Pressing the «TEMP» button (up-down), set the desired air temperature

indoors (except for FAN mode).

4.Pressing the «FAN SPEED» button on the remote control board, select

the fan rotation speed: AUTO, LOW, MIDDLE, HIGH, and the conditioner

will start working in accordance with the selected setting. In the Smart

mode fan speed automatically selected.

5.To turn the conditioner off, press the «ON/OFF» button once again.

In the FAN mode air temperature indoors is not set.

DRY

Turn the conditioner on pressing the «ON/OFF» button. Pressing the

«MODE» button, select the DRY mode. The conditioner will start working

in the set mode. To turn the conditioner off, press the «ON/OFF» button

once again.
