www.timberk.com • Electric air conditioner

Model AC TIM 07H S10B AC TIM 09H S10B AC TIM 12H S10B AC TIM 18H S10B AC TIM 21H S10B AC TIM 27H S10B

Indoor unit AC TIM 07H S10B AC TIM 09H S10B AC TIM 12H S10B AC TIM 18H S10B AC TIM 21H S10B AC TIM 27H S10B

Outdoor unit

AC TIM 07HS10B-01 AC TIM 09H S10B-01 AC TIM 12H S10B-01 AC TIM 18HS10B-01 AC TIM 21H S10B-01 AC TIM 27H S10B-01

Electrical protection

class

I class I class I class I class I class I class

Degree of protection

against moisture

(indoor unit)

IPX0 IPX0 IPX0 IPX0 IPX0 IPX0

Degree of protection

against moisture

(outdoor unit)

IP24 IP24 IP24 IP24 IP24 IP24

Refrigerant piping,

Liquid side/Gas side,

(inch)

1/4+3/8 1/4+3/8 1/4+3/8 1/4+1/2 1/4+1/2 3/8+5/8

Max. refrigerant pipe

length, (m)

15 15 15 15 15 15

Maximum difference

in level, m

5 5 5 5 5 5

Filling of Freon, (g) 410 590 700 1200 1450 1450

Operating temperature

range: cooling, ° C

+18 ~ +43 +18 ~ +43 +18 ~ +43 +18 ~ +43 +18 ~ +43 +18 ~ +43

Operating temperature

range: heating, ° C

-7 ~ + 24 -7 ~ + 24 -7 ~ + 24 -7 ~ + 24 -7 ~ + 24 -7 ~ + 24
