ASSEMBLING

· First put the unit upside down.

· Install multidirectional rolling wheels to each end

between the first and the second groups of the

radiating flanges.

· Let the  shape screw surrounding the dome of the

radiating flanges. Then insert it into two holes of the

supporting plate.

· Insert the butterfly nuts and screw them tightly counter

clockwise.

USING THE APPLIANCE

· Set the thermostat to  position and power selector to  position, insert the plug to the

power supply.

POWER SELECTOR

· You can adjust power of work of an oil heater, using power regulator:

- Off;

- minimal power;

-  medium power;

-  - maximal power;

THERMOSTAT

· Set the thermostat to  position.

· When the temperature rises to which you are satisfied with, slowly turn the thermostat

counterclockwise until the indicator lights is out, and the room temperature thus can keep

constant.

· If you want to change the room temperature, you can make another regulation: turn the

thermostat clockwise to rise the temperature and counterclockwise to lower it, or turn the

power selector to  position.

NOTES:

· The room must be sealed in good condition, if not, it will not make good result because of

the influx of heat.

· After use, turn the power selector to the  position, then turn the thermostat to the 

position and unplug from power supply.

MODEL POWER REGULATION

RANGE (W)

SC-1163

600/900/1500

SC-1164

800/1200/2000

SC-1165

1000 /1500/2500
