VX-8DR/DE OPERATING MANUAL10
INSTALLATION OF ACCESSORIES
While the battery is being charged, the display will indicate “CHARGING” and the key
will glow red. The S-meter will deflect according to the charging status. When charging is
finished, the display will change to indicate “COMPLETE” and the key will glow green.
In the USA Version, the key is not lit when charging or when charging is complete.
When the charge is complete, the transceiver turns off after 3 minutes.
1) Turn the radio off while charging the battery.
2) Perform the battery charging where the ambient temperature range +41
°F to +95 °F (+5 °C to +35 °C). Charge out of this range could cause damege
to the battery pack.
3) Use only the Yaesu Musen Co., Ltd. model PA-44B/C/U or SAD-11B Battery Charger.
BATTERY LIFE INFORMATION
When the battery charge is almost depleted, a “Low Voltage” indicator will appear on the
display. When this icon appears, it is recommended that you charge the battery soon.
(1) TX 6 sec., RX 6 sec. and Squelched 48 sec (continuous operating cycle).
(2) Continuous signal reception.
The present battery voltage can be displayed manually on the LCD, by following the
instructions on page 119.
Battery capacity may be reduced during extremely cold weather. Keeping the radio inside
your parka may help preserve the full charge capacity.
OPERATING BAND
50 MHz
(1)
144 MHz
(1)
222 MHz
(1)
(
USA version
)
430 MHz
(1)
Broadcast Band
(2)
FNB-101LI
5.5 hours
5.0 hours
6.0 hours
5.0 hours
13 hours
FBA-39
20 hours
17 hours
20 hours
16 hours
20 hours
BATTERY INDICATOR
: Full battery power
: Enough battery power
: Low battery power
: Poor battery power
(
w/Blink
)
: charge
(or replace) the battery
BATTERY LIFE
(
APPROX.
)
FNB-102LI
9.0 hours
8.5 hours
11 hours
8.0 hours
20 hours
INSTALLATION OF FNB-101LI BATTERY PACK
