ENGLISH
10
Custom setup page
This is page is available only when no disc in the tray.
• TV type
Your player supports all TV systems. You can choose PAL, NTSC or AUTO
(multi system mode).
AUTO (multi system mode): TV system is switched automatically
according to disk color system.
NTSC: this system is employed in USA, Taiwan, Japan and etc.
PAL: this system is employed in China, Europe, Hong Kong and etc.
• РВС (playback control)
You can switch on or off this function of playback control (РВС function).
• Sound (choosing language), subtitle, disk menu
These parameters could be preset according to your preferences. If
preset parameters are supported by disk’s content, playback is going
on according to your settings. Otherwise disk’s default settings are
used. You can change playback settings by pressing buttons AUDIO and
SUBTITLE.
• Parental control function
This function is intended for parental control of disk content during
playback and protects your children from watching the objectionable
scenes. Disk with lever higher then the level preset by this function will
not be played.
• Default
Return to factory settings.
Password setup
• Password mode
When password mode is OFF, you can set parental control level (menu
Custom preference page -> Parental control).
In order to make change of parental control level impossible, switch on
password mode.
• Password
You can change password using this option. Select Password ->
Change. Input the old password in pop-up window (or default password
– 16900), then input new password and input new password again.
Press PLAY button to save new password.
Main functions
POWER (power supply on)
• Press button STANDBY located on front panel of DVD player or
POWER button on remote control to switch on player’ power supply.
• Use POWER button located on remote control to switch to standby
mode.
OPEN/CLOSE (disk tray open/close)
• Press button OPEN/CLOSE located on front panel of DVD player
or button on remote control to open disk tray. Load a disk into
tray by its operating surface looking down (label up). Press button
OPEN/CLOSE once more to close the tray, player will start playback
automatically. (For МРЗ and JPEG disks function of automatic
playback is not applicable.)
VOLUME (volume level adjustment)
• Use buttons VOLUME +/- to increase or decrease volume level.
MUTE (sound off)
• Press button MUTE to switch off the sound completely. Press button
MUTE or volume control buttons once more to switch on the sound.
PLAY/PAUSE (play back on/play back pause)
• Press button ► located on remote control or on front panel of DVD
player to start playback. To stop playback press button PAUSE
located on remote control or on front panel of DVD player. To return
to normal playback mode press button ►.
STOP (play back stop)
• When playing back DVD, SVCD, VCD, CD disks press button STOP
once, player will remember the point of stop. Press button ► located
on remote control or on front panel of DVD player to continue. Press
STOP button second time to stop player completely.
F.REV ◄◄ and F.FWD ►► (rewind/wind forward)
• Press button F.FWD ►► for fast winding forward
• Press button F.REV ◄◄ for fast rewind
PREV I◄◄/ NEXT ►►I (skip to previous/next track)
• When playing back DVD disks press button PREV (I◄◄) located on
remote control or on front panel of DVD player to skip to previous
chapter.
• When playing back SVCD, VCD, CD disks press button PREV (I◄◄)
to skip to previous track.
• When playing back DVD disks press button NEXT (►►I) located
on remote control or on front panel of DVD player to skip to next
chapter.
• When playing back SVCD, VCD, CD disks press button NEXT (►►I)
to skip to next track.
PROG (programming)
• If disk includes two or more tracks, chapters or titles you can set
your own playback order using this button.
• Press button PROG to enter programming mode, program menu
appears on the screen. Press number buttons to set number of
track, chapter or title. To set number 10 and more use button
10+. For example, to input number 6 press the next sequence of
buttons: 10+, 10+, 6. If there are more then 10 entries, press NEXT
►►I to continue program table (maximal number of entries is 0).
Use cursor buttons (↓→←↑) to move cursor. After the program is
completed select menu item “start” using cursor buttons and press
button ► to start playback of programmed sequence.
• Programming is not applicable for МРЗ, DiV X disks. Pres button
PROG once to open file list. You can select a file you need to play
using cursor buttons.
TITLE/PBC (titles/playback control)
• When playing back DVD disks press button TITLE/PBC to display
main menu (in case of some disks – to go to disk menu).
• When playing back SVCD, VCD.0 disks press button TITLE/PBC to
display disk menu.
After disk have been loaded, if PBC function is ON player displays
menu automatically (see custom settings page in system setup
menu). In this mode you can choose track number by pressing the
adequate number button.
Press button TITLE/PBC, on TV screen will be displayed “РВС OFF”,
in this mode disk playback is started automatically.
VCD1.1, CDDA and МРЗ do not have РВС menu.
MENU (menu)
• When playing back DVD disks press button MENU to open disk’s
menu.
SUBTITLE (subtitles selection)
• When playing DVD disk with subtitles press button SUBTTITLE to
choose subtitle language.
ANGLE (view angle)
• When playing DVD disk with more then one view angle press button
ANGLE to choose the angle you need.
4119IM.indd 10 20.02.2008 15:16:09
