Nivona CafeRomatica 778 NICR 778 [12/16] Cleaning and maintenance
![Nivona CafeRomatica 768 NICR 768 [12/16] Cleaning and maintenance](/views2/1304007/page12/bgc.png)
Note: Should you have started the process accidentally or too early, you can change the quantity dur-
ing preparation.
When the “ml” display is blinking, turn the left rotary control to the required position.
If you want to stop the process, press the right rotary control again.
Note: If you have opened the lid of the ground coffee chute accidentally or did not press the right
rotary control after having poured in the ground coffee, the appliance will automatically start rinsing
for a minute once the lid is closed (g. 1/E). It will then be operational again.
Attention: The ground coffee chute is not a storage container. Therefore never pour in more than one
portion of coffee and only use fresh or vacuum-packed coffee ground from coffee beans. Do not use
water-soluble instant coffee!
5. Cleaning and maintenance
Your NIVONA appliance will ask you for some of the cleaning and maintenance programmes listed
below (e.g. “RINSE FROTHER”). They are shown in the display.
If a cleaning or maintenance call appears, turn the right rotary control in the main menu to the
“hand symbol with raised index nger”. Press the right rotary control.
The appliance will start the required cleaning or maintenance process and the display will inform you
if further action is required.
Follow the instructions in the display. If in doubt check in the following 5.1. to 5.9.
5.1. Rinsing the milk frother
Attention: Do not disrupt the running programme!
You should rinse the frother after each drink for which milk was used, but denitely when the display
asks you to do so.
Turn the right rotary control to “MAINTENANCE” and press it.
Turn the right rotary control to “RINSE FROTHER” and press it.
The display shows “HOSE ON SPOUT AND IN DRIP TRAY”.
Connect the hose provided to one end of the height-adjustable spout (g. 7).
Connect the other end to the back of the drip tray on the right (g. 10).
Place a sufciently large bowl (at least 0.5 l) underneath the height-adjustable spout.
Press the right rotary control.
The display shows “RINSING FROTHER, DO NOT REMOVE HOSE”. The appliance starts the clean-
ing process. Once the cleaning cycle is nished the appliance reheats and is ready for use. The
display shows the main menu.
5.2. System rinsing
From time to time the system should be rinsed. Proceed as follows
Turn the right rotary control to “MAINTENANCE” and press it.
Turn the right rotary control to “SYSTEM RINSING” and press it.
The display shows “RINSING SYSTEM”.
Once the rinsing cycle is nished, the appliance reheats and is ready for use. The display shows the
main menu.
5.3. Cleaning frother
Attention: Do not disrupt the running programme!
Note: When it is required the display will show “PLEASE CLEAN FROTHER”.
Proceed as follows:
Turn the right rotary control to “MAINTENANCE” and press it.
Turn the right rotary control to “CLEAN FROTHER” and press it.
The display alternately shows “EMPTY TRAYS” and “FILL WATER”.
Remove the drip tray and the used coffee container (g. 1/N and 1/O) and empty both.
If necessary rell the water tank with fresh water. Reinsert the water tank rst, followed by drip
tray and the used coffee container.
The display shows “HOSE ON SPOUT AND IN CLEANER”.
Connect one end of the hose to the height-adjustable spout (g. 7).
Put some detergent (available as an optional accessory, see 8.) and water in a container, amount-
ing to at least 0.3l. For the correct mix ratio follow the detergent manufacturer’s instructions.
Dip the other end of the hose into the cleaning solution.
Place a sufciently large bowl (at least 0.5 l) underneath the height-adjustable spout.
Press the right rotary control.
The display shows “START CLEANING”.
Press the right rotary control.
The appliance starts the cleaning process. The display shows
“CLEANING FROTHER. DO NOT REMOVE HOSE”.
After a short while the display shows “HOSE ON SPOUT AND IN DRIP TRAY”
Connect one end of the hose to the height-adjustable spout (g. 7) and the other end to the drip
tray (g. 10).
Press the right rotary control.
The display shows “CLEANING FROTHER, DO NOT REMOVE HOSE”.
Once the cleaning cycle is nished, the appliance starts heating up and is again ready for use.
Empty the drip tray and used coffee container (g. 1/N and 1/O) and reinsert them when cleaned.
The display shows the main menu.
5.4. System cleaning
Note: If the appliance needs cleaning, the display will show “PLEASE CLEAN SYSTEM”. You can continue
making coffee, but we recommend starting the cleaning programme as soon as possible. Otherwise your
warranty could be compromised.
Attention: Do not disrupt the cleaning process. Insert cleaning tablet only when the appliance asks for it.
Turn the right rotary control to “MAINTENANCE” and press it.
Turn the right rotary control to “CLEAN SYSTEM” and press it.
The display alternately shows “EMPTY TRAYS” and “FILL WATER”.
If necessary rell the water tank with fresh water. Reinsert the water tank.
Remove the drip tray and used coffee container (g. 1/N and 1/O), empty both and reinsert them.
The appliance rinses twice. The display shows “CLEANING SYSTEM”.
The display then shows “CLEANING TAB IN GROUND COFFEE CHUTE”.
Place a sufciently large bowl (at least 0.5 l) underneath the spout (g. 1/E).
Open the lid of the ground coffee chute (g. 1/M).
Place a cleaning tablet in the chute and close both lids.
The display shows “START CLEANING”.
Press the right rotary control.
82 83
4. Preparing coffee specialities / 5. Cleaning and maintenance 5. Cleaning and maintenance
