10. CSM (Consumer Setup menu)

The CSM contains data about the TV software, serial number and other details. The menu can be accessed using a

standard remote control or using the master remote control.

1.Usingthestandardremotecontrol:pressthefollowingkeysequence“1,2,3,6,5,4”

2. Using master remote control (22AV8753D): Press the RECALL button for the CSM.

Notes: Activation of the CSM is only possible if there is no (user) menu on the screen.

The CSM data are also stored on the USB during the cloning from USB to TV. The data are stored in the folder CSM

Dump which is inside of the cloning folder TPN141HE_CloneData.

The text file which contains all the data will have the name composed from the model number and serial number of

theTV.Filecanbeviewedusinganytexteditoranddoesn’taffectthecloningdata.

Content of the file looks like this:

1.1 Set Type: 28HFL5009D/12

1.2 Production code: FZ1A1425043274

1.3 Installation date: 140630

1.4a Option Code 1: 000 016 067 000 000 000 000 068

1.4b Option Code 2: 002 002 064 065 010 014 105 000

1.5 SSB: 905TXESCF0100100SX

1.6 Display: 750TBV275A01C2N000

1.7 PSU: PLTVDF261XXJ6

2.1 Current Main Software: TPN142HE_004.002.013.128

2.2 Development SW Version: TPN142HE_005.001.211.037
