PALACE ONE

Basin mixer / basin mixer with sidespray / kitchen mixer installation

1. Disconnect your water supply system.

2. Connect a  exible pipe to the mixer.

Important! To prevent damage to the  exible pipe, twist it into the mixer body manually,

do not use any tools or apply extensive force.

4. Attach mixer to a sanitary ware using the supplied  ttings.

5. Connect the  exible pipe to water supply system: the right hose to cold water supply, the

left hose — to hot water supply.

6. Before connecting the mixer it is recommended to remove (unscrew) the aerator in order to

prevent its clogging at the  rst water feed.

7. Start the water supply system with the mixer in «closed» position and make sure that all

connections are tight. Perform additional connections tightening and sealing if necessary.

8. Open hot and cold water supply for a while, then close water supply and re-install (screw in)

the aerator.

Bath/shower mixer, bath/shower mixer with a long spout / bath/

shower mixer with a long spout and shower set and shower mixer

installation

1. Disconnect your water supply system. Screw eccentric reducers into the water supply

system pipes after sealing the threads with sealing material. Select a position of eccentric

reducers to match and comply with the mixer’s connections position. The mixer should be

in a horizontal position.

2. Before connecting the mixer it is recommended to remove (unscrew) the aerator in order to

prevent its clogging at the  rst water feed.

3. Install decorative plates on the eccentric reducers and connect the mixer’s body using tools

with soft extensions. Install a spout to a bath/shower mixer with a long spout.

4. Start the water supply system with the mixer in «closed» position and make sure that all

connections are tight. Perform additional connections tightening and sealing if necessary.

5. Open hot and cold water supply for a while, then close water supply and re-install (screw in)

the aerator.

6. For bath/shower mixer with a long spout and shower sets attach shower head to the hose

using insertions. Connect the hose to the shower slot on the mixer body. Install wall bracket

for shower head in a convenient place for you.

Warning!

Mixers can operate normally with the following water supply system speci cations:

• Operating pressure interval in water mains is 0.5-6.0 atm. (50-620 kPa).

• Pressure di erence in hot and cold water supply systems can vary up to 10%. If it exceeds this

value, the pressure increase/decrease instruments installation is recommended.

• Maximum allowable hot water temperature: +80С°.

• Install 100-300 μ  lters to prevent foreign objects (abrasive particles) from getting inside the

item.
