17
Specifications
Continued from previous page
RAID
Intel
®
Z370 Chipset
y Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
USB
y Intel
®
Z370 Chipset
8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A
ports on the back panel, 4 ports available through the
internal USB connectors)
6x USB 2.0 (High-speed USB) ports (2 Type-A ports on
the back panel, 4 ports available through the internal
USB connectors)
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
LAN 1x Intel
®
I219-V Gigabit LAN controller
Back Panel
Connectors
y 1x PS/2 mouse / keyboard combo port
y 2x USB 2.0 ports
y 1x VGA port
y 1x DVI-D port
y 1x DisplayPort port
y 1x LAN (RJ45) port
y 4x USB 3.1 Gen1 Type-A ports
y 6x OFC audio jacks
Continued on next page
