Sony FD TRINITRON KV-14LT1K [11/42] Specifications
![Sony FD TRINITRON KV-14LT1K [11/42] Specifications](/views2/1307690/page11/bgb.png)
11
17
GB
Specifications
Additional Information
TV system:
B/G/H, D/K
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage:
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12, R21-R69
Picture Tube:
Flat Display FD Trinitron
Rear Terminals
:1/
21-pin scart connector
(CENELEC standard)
including audio/video
input, RGB input, TV audio/
video output.
Front Terminals
…2 video input – phono jack
2 audio input – phono jack
headphones jack
Design and specifications are subject to change without notice.
Ecological Paper- Totally Chlorine Free
Sound Output:
• KV-21LT1K:
1 x 8 W (music power)
1 x 4 W (RMS Mono)
• KV-14LT1K:
1 x 6 W (music power)
1 x 3 W (RMS Mono)
Power Consumption:
• KV-21LT1K: 55 W
• KV-14LT1K: 42 W
Standby Power Consumption:
≤ 0.55 W
Dimensions (w x h x d) :
• KV-21LT1K: Approx. 514 x 478 x 487 mm.
• KV-14LT1K: Approx. 393 x 358 x 415 mm.
Weight:
• KV-21LT1K: Approx. 24 Kg.
• KV-14LT1K: Approx. 11.5 Kg.
Accessories supplied:
1 Remote Control (RM-887)
2 Batteries (IEC designated)
1 Aerial (only for KV-14LT1K)
Other features:
•Teletext, Fastext, TOPtext
•Sleep Timer
•Wake UP Timer
•Smartlink (direct link between your TV set
and a compatible VCR. For more
information on Smartlink, please refer to
the Instruction Manual of your VCR).
•TV system Autodetection.
18
Troubleshooting
Here are some simple solutions to the problems which may affect the picture and sound.
Additional Information
Problem
No picture (screen is dark) and no
sound.
Poor or no picture (screen is dark),
but good sound.
No picture or no menu information
from the equipment connected to the
Scart connector.
Good picture, no sound.
No colour on colour programmes.
Distorted picture when changing
programmes or selecting teletext.
Picture slanted (only for
KV-21LT1K)
Noisy picture when viewing a TV
channel.
Remote control does not function.
The standby indicator on the TV
flashes even though the “On Timer”
Solution
•Check the aerial connection.
• Plug the TV in and press the button on the front of
TV.
•If the standby indicator is on, press button on
the remote control.
•Using the menu system, select the “Picture
Adjustment” menu and select “Reset” to return to the
factory settings.
•Check that the optional equipment is on and press the
button repeatedly on the remote control until the
correct input symbol is displayed on the screen.
• Press the +/- button on the remote control.
• Using the menu system, select the “Picture
Adjustment” menu and select “Reset” to return to
factory settings.
• Turn off any equipment connected to the Scart
connector on the rear of the TV.
• Using the menu system, select the “Picture Rotation”
option in the “Advanced Features” menu to correct the
picture slant.
• Using the menu system, select the “Manual
Programme Preset” menu and adjust Fine Tuning
(AFT) to obtain better picture reception.
• Using the menu system, select the “Noise Reduction”
option in the “Advanced Features” menu and select
“On” to reduce the noise in the picture.
• Replace the batteries.
• Contact to your nearest Sony service centre.
In case of problems, have your TV serviced by qualified personnel. Never open the
casing yourself.
