English
5
Z370 Killer SLI/ac / Z370 Killer SLI
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Con-
trol)
•
1 x Chassis Optional/Water Pump Fan Connector (4-pin)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
1 x underbolt AIC Connector (5-pin)
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection)
•
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)
(Supports ESD Protection)
•
1 x Front Panel Type C USB 3.1 Gen1 Header
•
1 x Performance Mode / Easy OC Header
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU Vcore, DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA
Voltage Multi-adjustment
Hardware
Monitor
•
Temperature Sensing: CPU, Chassis, Chassis Optional/Wa-
ter Pump Fans
•
Fan Tachometer: CPU, Chassis, Chassis Optional/Water
Pump Fans
•
Quiet Fan (Auto adjust chassis fan speed by CPU tempera-
ture): CPU, Chassis, Chassis Optional/Water Pump Fans
•
Fan Multi-Speed Control: CPU, Chassis, Chassis Optional/
Water Pump Fans
•
CASE OPEN detection
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
VPPM, PCH 1.0V, VCCSA, VCCST
OS
•
Microso® Windows® 10 64-bit
