Gigabyte Z370 HD3P [11/44] Center subwooferspeakerout orange

USB3.1Gen1Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

HDMI Port

The HDMI port supports HDCP 2.2 and Dolby TrueHD and DTS HD Master

Audioformats.Italsosupportsupto192KHz/16bit8-channelLPCMaudio

output. You can use this port to connect your HDMI-supported monitor. The maximum supported

resolutionis 4096x2160@30 Hz,butthe actual resolutions supportedaredependent on the monitor

being used.

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

RearSpeakerOut(Black)

Thisjackcanbeusedtoconnectrearspeakersina4/5.1/7.1-channelaudioconguration.

SideSpeakerOut(Gray)

Usethisaudiojacktoconnectsidespeakersina7.1-channelaudioconguration.

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

LineOut(Green)

The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended

that you connect your headphone/speaker to this jack (actual effects may vary by the device being used).
