Gigabyte Z370M DS3H [4/44] Z370m ds3h motherboard
![Gigabyte Z370M DS3H [4/44] Z370m ds3h motherboard](/views2/1307935/page4/bg4.png)
- 4 -
Z370M DS3H Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 Z370M DS3H Motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS_USB
DVI
HDMI
R_USB30
USB30_LAN
LGA1151
ATX
AUDIO
DDR4_4
DDR4_2
DDR4_3
DDR4_1
ATX_12V_2X4
Intel
®
Z370
CLR_CMOS
M_BIOS
B_BIOS
PCIEX1_1
PCIEX16
PCIEX1_2
F_USB30
M2A_32G
CODEC
Z370M DS3H
F_PANELF_USB2 F_USB1TPMF_AUDIO
COM
LPT
SPDIF_O
SYS_FAN
CPU_FAN
iTE
®
Super I/O
426080
SATA3SATA3
3 1
2 0
5
4
BAT
Realtek
®
GbE
LAN
