1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/SYS_FAN2
5) SATA3 2/3/4/5
6) M2A_32G/M.2
7)
LED_C
8)
D_LED
9)
DLED_V_SW1
10) F_PANEL
11) F_AUDIO
12) SPEAKER
13) SPDIF_O
14) F_USB30
15) F_USB1
16) BAT
17) CLR_CMOS
18) CI
31 4 6
16
2
5
7
8
9
10
11
12
13
14
15
17
18
- 13 -
