USER MANUAL

Revision 1.0c

X11SSM(-F)

X11SSL(-F)

Содержание

Warning handling of lead solder materials used in this product may expose you to lead a chemical known to the state of california to cause birth defects and other reproductive harm 2
About this manual 3
About this motherboard 3
Conventions used in the manual 3
Preface 3
Contacting supermicro 4
Chapter 1 introduction 5
Chapter 2 installation 5
Table of contents 5
Appendix a bios codes appendix b software installation 6
Appendix c standardized warning statements 6
Appendix d uefi bios recovery appendix e dual boot block 6
Chapter 3 troubleshooting 6
Chapter 4 bios 6
Chapter 1 7
Checklist 7
Important links 7
Introduction 7
Bar code 10
Com2 yes no 10
Differences between x11ssm f x11ssl f 10
Figure 1 3 x11ssm f x11ssl f motherboard layout 10
I sata6 i sata7 yes no 10
Ipmi code 10
Ipmi lan yes x11ssm f yes x11ssl f 10
Mac code 10
Note components not documented are for internal testing only 10
Pci e slot 4 yes no 10
X11ssm f x11ssl f 10
X11ssm f x11ssl f user manual 10
Chapter 1 introduction 11
Indicates the location of pin 1 11
Jumpers led indicators not indicated are used for testing only 11
Nections 11
Please refer to the table on page 10 to see model variations 11
Power cable before installing or removing any components 11
Quick reference 11
See chapter 2 for detailed information on jumpers i o ports and jf1 front panel con 11
When ledpwr onboard power led indicator is on system power is on unplug the 11
Connector description 12
Jumper description default setting 12
Led description status 12
Note table is continued on the next page 12
Quick reference table 12
X11ssm f x11ssl f user manual 12
Chapter 1 introduction 13
Connector description 13
Motherboard features 14
Note the table above is continued on the next page 14
X11ssm f x11ssl f user manual 14
Chapter 1 introduction 15
Motherboard features 15
Note the table above is continued on the next page 15
Bmc ast2400 17
Chapter 1 introduction 17
Figure 1 4 17
Note this is a general block diagram and may not exactly represent the features on your motherboard see the previous pages for the actual specifications of your moth erboard 17
Skt h4 lga1151 17
System block diagram 17
Processor and chipset overview 18
Recovery from ac power loss 18
Special features 18
Acpi features 19
Environmental temperature control 19
Fan status monitor with firmware control 19
Onboard voltage monitors 19
System health monitoring 19
System resource alert 19
Power supply 20
Serial port 20
Chapter 2 21
Installation 21
Precautions 21
Static sensitive devices 21
Unpacking 21
All motherboards have standard mounting holes to fit different types of chassis make sure that the locations of all the mounting holes for both the motherboard and the chassis match although a chassis may have both plastic and metal mounting fasteners metal ones are highly recommended because they ground the motherboard to the chassis make sure that the metal standoffs click in or are screwed in tightly 22
Location of mounting holes 22
Mac code 22
Motherboard installation 22
Note 1 to avoid damaging the motherboard and its components please do not use a force greater than 8 lb inch on each mounting screw during motherboard installation 2 some components are very close to the mounting holes please take precautionary measures to avoid damaging these components when installing the motherboard to the chassis 22
Philips 22
Philips screws 22
Screwdriver 22
Standoffs 7 only if needed 22
Tools needed 22
X11ssm f x11ssl f user manual 22
Installing the motherboard 23
Installing the lga1151 processor 24
Processor and heatsink installation 24
Installing an active cpu heatsink with fan 27
Removing the active heatsink 29
Installing a passive cpu heatsink 30
Removing the passive heatsink 31
Dimm module population configuration 32
For optimal memory performance follow the table below when populating memory 32
Important exercise extreme care when installing or removing dimm modules to pre vent any possible damage 32
Memory module population 32
Memory module population for optimal performance 32
Memory support 32
Memory support and installation 32
Note check the supermicro website for recommended memory modules 32
Processors and their corresponding memory modules 32
The x11ssm f x11ssl f motherboard supports up to 64gb of unbuffered udimm ddr4 ecc 2133 1866 1600 1333mhz memory in four memory slots populating these dimm slots with memory modules of the same type and size will result in interleaved memory which will improve memory performance 32
X11ssm f x11ssl f user manual 32
Always use ddr4 dimm modules of the same type size and speed 33
Bar code 33
Chapter 2 installation 33
Dimm module population sequence 33
Dimma1 33
Dimma2 blue slot 33
Dimma2 dimmb1 33
Dimmb1 33
Dimmb2 33
Dimmb2 blue slot 33
For best memory performance install dimm modules in pairs to activate memory interleav ing 33
Ipmi code 33
Mac code 33
Mixed dimm speeds can be installed however all dimms will run at the speed of the 33
Slowest dimm 33
The motherboard will support odd numbered modules 1 or 3 modules installed however 33
Towards the cpu 33
Towards the edge of the motherboard 33
When installing memory modules the dimm slots should be populated in the following order dimmb2 dimma2 dimmb1 dimma1 33
Align the key of the dimm module with the 34
Align the notches on both ends of the 34
Bar code 34
Dimm installation 34
Dimm removal 34
Ends of the dimm slot to unlock it 34
Insert the desired number of dimms into 34
Ipmi code 34
Mac code 34
Module against the receptive points on the ends of the slot 34
Notches 34
Notches on both ends of the module straight down into the slot until the module snaps into place 34
Press both notches straight down into the memory slot 34
Press both release tabs on the ends of the dimm module to unlock it once the dimm module is loosened remove it from the memory slot 34
Press the release tabs to the lock positions 34
Push the release tabs outwards on both 34
Receptive point on the memory slot 34
Release tabs 34
The memory slots starting with dimmb2 channel b slot 2 blue slot for best performance please use the memory modules of the same type and speed in the same bank 34
To secure the dimm module into the slot 34
Use two thumbs together to press the 34
X11ssm f x11ssl f user manual 34
9 8 7 6 35
Chapter 2 installation 35
Com1 port 6 usb6 3 35
Description description 35
Figure 2 2 i o port locations and definitions 35
Ipmi lan 7 lan1 35
Rear i o ports 35
See figure 2 2 below for the locations and descriptions of the various i o ports on the rear of the motherboard 35
Usb0 9 vga port 35
Usb1 8 lan2 35
Usb7 3 10 uid switch 35
A video vga port is located next to lan2 on the i o back panel refer to the board layout below for the location 36
Com port 36
Com2 x11ssm f only 36
Dcd 6 dsr 36
Dtr 9 ri 36
Ground 10 n a 36
One com connection com1 is located on x11ssm f x11ssl f on the i o back panel x11ssm f has an additional com connection com2 located next to com1 see the table below for pin definitions 36
Pin definition pin definition 36
Pin definitions 36
Rxd 7 rts 36
Serial ports 36
Txd 8 cts 36
Vga port 36
X11ssm f x11ssl f user manual 36
Chapter 2 installation 37
Ipmi lan f versions only 37
Lan ports 37
Two gigabit ethernet ports lan1 and lan2 are located on the i o back panel on the motherboard in addition a dedicated ipmi lan is located above usb 0 1 ports on the back panel on the f boards all of these ports accept rj45 cables please refer to the led indicator section for lan led information 37
There are two usb 2 ports usb0 1 and two usb 3 ports usb6 7 located on the i o back panel the motherboard also has two front access usb 2 headers usb2 3 and usb4 5 and one front access usb 3 header usb8 9 the usb10 header is usb 3 type a the onboard headers can be used to provide front side usb access with a cable not included 38
Universal serial bus usb ports 38
X11ssm f x11ssl f user manual 38
Chapter 2 installation 39
Usb0 1 39
Usb2 3 39
Usb4 5 39
Usb6 7 39
Usb8 9 39
Bar code 40
Figure 2 3 jf1 header pins 40
Fp pwrled 40
Front control panel 40
Ground 40
Ground sw_nmi_n 40
Hdd led 40
Ipmi code 40
Jf1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis these connectors are designed specifically for use with supermicro chassis see the figure below for the descriptions of the front control panel buttons and led indicators 40
Mac code 40
Nic1 link active led 40
Nic2 link active led 40
Oh fan fail led 40
P3v3_stby 40
P3v3_stby id_uid_sw 40
Power button 40
Power fail led 40
Reset button 40
Uid led 40
X11ssm f x11ssl f user manual 40
Chapter 2 installation 41
Ground 41
Pin definitions jf1 41
Power button 41
Pwr button 41
Reset button 41
Signal 41
The power button connection is located on pins 1 and 2 of jf1 momentarily contacting both pins will power on off the system this button can also be configured to function as a suspend button with a setting in the bios see chapter 4 to turn off the power when the system is in suspend mode press the button for 4 seconds or longer refer to the table below for pin definitions 41
The reset button connection is located on pins 3 and 4 of jf1 attach it to a hardware reset switch on the computer case refer to the table below for pin definitions 41
Blue led 42
Connect an led cable to pins 7 and 8 of the front control panel to use the overheat fan fail led connections the led on pin 8 provides warnings of overheat or fan failure refer to the tables below for pin definitions 42
Flashing fan fail 42
Off normal 42
Oh fan fail indicator 42
Oh fan fail led 42
On overheat 42
Overheat oh fan fail 42
Pin definitions jf1 42
Power fail led 42
Pwr fail led 42
Pwr supply fail 42
Status 42
The power fail led connection is located on pins 5 and 6 of jf1 refer to the table below for pin definitions 42
X11ssm f x11ssl f user manual 42
3 v stdby uid_sw 43
Chapter 2 installation 43
Hdd active 43
Hdd led 43
Hdd led uid switch 43
Lan1 lan2 led 43
Nic 1 activity led 43
Nic 1 link led 43
Nic 2 activity led 43
Nic 2 link led 43
Nic1 led 43
Nic1 nic2 lan1 lan2 43
Nic2 led 43
Pin definitions jf1 43
The hdd led uid switch connection is located on pins 13 and 14 of jf1 attach a cable to pin 14 to show hard drive activity status attach a cable to pin 13 to use uid switch refer to the table below for pin definitions 43
The nic network interface controller led connection for lan port 1 is located on pins 11 and 12 of jf1 and the led connection for lan port 2 is on pins 9 and 10 attach the nic led cables here to display network activity refer to the table below for pin definitions 43
Control 44
Ground 44
Nmi button 44
Pin definitions jf1 44
Power led 44
Pwr led 44
The non maskable interrupt button header is located on pins 19 and 20 of jf1 refer to the table below for pin definitions 44
The power led connection is located on pins 15 and 16 of jf1 refer to the table below for pin definitions 44
X11ssm f x11ssl f user manual 44
Chapter 2 installation 45
Connectors 45
Main atx power supply connector 45
Megerac license 45
Pin atx main pwr 45
Power connections 45
The primary power supply connector jpwr1 meets the atx ssi eps 12v specification you must also connect the 8 pin jpwr2 processor power connector to your power supply 45
12v 8 pin power 46
4 ground 46
Important to provide adequate power supply to the motherboard be sure to connect the 24 pin atx pwr and the 8 pin pwr connectors to the power supply failure to do so may void the manufacturer warranty on your power supply and motherboard 46
Jpwr2 must also be connected to the power supply this connector is used to power the processor s 46
Pin definition 46
Pin definitions 46
Pin pwr 46
Required connection 46
Secondary power connector 46
X11ssm f x11ssl f user manual 46
2 a 12v red 47
Chapter 2 installation 47
Fan header 47
Fan headers 47
Ground black 47
Headers 47
Pin definitions 47
Pwm_control 47
Tachometer 47
The x11ssm f x11ssl f has five fan headers fan1 fan4 fana all of these 4 pin fan headers are backwards compatible with the traditional 3 pin fans however fan speed control is available for 4 pin fans only by thermal management via the ipmi 2 interface refer to the table below for pin definitions 47
A chassis intrusion header is located at jl1 on the motherboard attach the appropriate cable from the chassis to inform you of a chassis intrusion when the chassis is opened refer to the table below for pin definitions 48
Chassis intrusion 48
Ground 48
Internal buzzer 48
Internal buzzer pin definitions 48
Internal speaker buzzer 48
Intrusion input 48
Neg alarm speaker 48
Pin definition 48
Pin definitions 48
Pos beep in 48
The internal speaker sp1 can be used to provide audible notifications using various beep codes refer to the table below for pin definitions refer to the layout below for the location of the internal buzzer 48
X11ssm f x11ssl f user manual 48
Blinking fan fail 49
Chapter 2 installation 49
Fp_pwr_led 49
Jd1_pin1 49
Oh active 49
Overheat fan fail led header 49
Overheat led header 49
Overheat led pin definitions 49
Pin definition 49
Pin definitions 49
Pin setting definition 49
Pins 1 3 of jd1 are used for power led indication and pins 4 7 are for the speaker please note that the speaker connector pins 4 7 are used with an external speaker if you wish to use the onboard speaker you should close pins 6 7 with a cap refer to the tables below for pin definitions 49
Power led speaker 49
Pwr led connector 49
R_spkpin 49
R_spkpin_n 49
Solid overheat 49
Speaker connector 49
Speaker header 49
State definition 49
Status 49
The joh1 header is used to connect an led indicator to provide warnings of chassis overheating and fan failure this led will blink when a fan failure occurs refer to the tables below for pin definitions 49
5v standby 50
Disk on module power connector 50
Dom power 50
Ground 50
Jsd 1 dom pwr 50
Jsd 2 dom pwr 50
Pin definition 50
Pin definitions 50
Standby power 50
Standby pwr 50
The 5v standby power header is located at jstby1 on the motherboard you must have a card with a standby power connector and a cable to use this feature refer to the table below for pin definitions 50
Two power connectors for sata dom disk_on_module devices are located at jsd1 jsd2 connect appropriate cables here to provide power support for your serial link dom devices 50
Wake on lan pin definitions 50
Wake up 50
X11ssm f x11ssl f user manual 50
Chapter 2 installation 51
Clock 8 nc 51
Gnd 4 data 51
I sgpio 1 51
I sgpio 1 2 51
I sgpio 2 51
I sgpio1 i sata 3 ports 0 3 51
I sgpio2 i sata 3 ports 4 7 51
Load 6 gnd 51
Nc 2 nc 51
Nc no connection 51
Pin definition pin definition 51
Sgpio header pin definitions 51
Sgpio headers 51
Two i sgpio serial link general purpose input output headers are located on the motherboard they support the onboard i sata 3 ports refer to the table below for pin definitions 51
3 v 10 lad1 52
3v stdby 16 serirq 52
A trusted platform module tpm port 80 header is located at jtpm1 to provide tpm support and a port 80 connection use this header to enhance system performance and data security refer to the table below for pin definitions 52
Gnd 18 clkrun 52
Lad0 12 gnd 52
Lad3 8 lad2 52
Lclk 2 gnd 52
Lpcpd 20 ldrq 52
Lreset 6 5v 52
Pin definition pin definition 52
Pin definitions 52
Smb_clk 14 smb_dat 52
Tpm header 52
Tpm port 80 header 52
Trusted platform module header 52
X11ssm f x11ssl f user manual 52
A system management bus header for ipmi 2 is located at jipmb1 connect the appropriate cable here to use the ipmb 53
Bmc external header 53
C connection on your system refer to the table below for pin definitions 53
C connector jp 53
C header 53
C1 monitors the power supply fan and system temperatures refer to the table below for pin definitions 53
Chapter 2 installation 53
External 53
Ground 53
Megerac license 53
Pin bmc external 53
Pin definition 53
Pin definitions 53
Pmbus_alert 53
Power smb 53
Power smb header 53
The power system management bus 53
Ground 54
I sata 6 7 two x11ssm f only 54
I sata0 54
I sata0 1 two 54
I sata1 54
I sata2 54
I sata2 5 four sata 3 6 gb s raid 0 1 5 10 54
I sata3 54
I sata4 54
I sata5 54
I sata6 x11ssm f only 54
I sata7 x11ssm f only 54
Note 1 i sata0 and i sata1 are supermicro superdoms these are yellow sata dom connectors with power pins built in and do not require separate external power cables these connectors are backward compatible with non supermicro satadoms that require an external power supply 54
Note 2 for more information on the sata hostraid configuration please refer to the intel sata hostraid user s guide posted on our website at http www supermicro com 54
Pin signal 54
Port connection type 54
Sata 3 6 gb s raid 0 1 5 10 superdom connectors 54
Sata 3 6 gb s raid 0 1 5 and 10 54
Sata 3 port pin definitions 54
Sata ports 54
Sata_rxn 54
Sata_rxp 54
Sata_txn 54
Sata_txp 54
Six sata 3 connectors are located on the x11ssm f x11ssl f motherboard supported by the intel c232 c236 pch chip these sata ports support raid 0 1 5 and 10 sata ports provide serial link signal connections which are faster than the connections of parallel ata see the tables below for pin definitions two additional sata 3 connectors i sata 6 7 are located on the x11ssm f motherboard 54
Supported by intel c232 c236 pch exp 54
Supported by intel c236 pch 54
X11ssm f x11ssl f sata 3 connector types 54
X11ssm f x11ssl f user manual 54
A unit identifier uid switch and an led indicator are located on the motherboard the uid switch is located at juidb1 which is next to the vga port on the back panel the uid led le1 is located next to the uid switch when you press the uid switch the uid led will be turned on press the uid switch again to turn off the led indicator the uid indicator provides easy identification of a system unit that may be in need of service 55
Blue on unit identified 55
Button in 55
Chapter 2 installation 55
Color status 55
Ground 55
Note uid can also be triggered via ipmi on the motherboard for more information on ipmi please refer to the ipmi user s guide posted on our website at http www supermicro com 55
Pin definition 55
Pin definitions 55
Uid led 55
Uid switch 55
Unit identifier switch uid led indicator 55
How jumpers work 56
Jumper settings 56
Chapter 2 installation 57
Cmos clear 57
Jbt1 is used to clear the cmos instead of pins this jumper consists of contact pads to prevent accidental clearing of the cmos to clear the cmos use a metal object such as a small screwdriver to touch both pads at the same time to short the connection 57
Jumper setting definition 57
Jumper settings 57
Jumpers jpl1 jpl2 enable or disable lan ports 1 2 on the motherboard refer to the table below for jumper settings the default setting is enabled 57
Lan port enable disable 57
Lan1 lan4 enable disable 57
Lan1 port enable disable 57
Lan2 port enable disable 57
Note be sure to completely shut down the system and then short jbt1 to clear the cmos 57
Pins 1 2 enabled 57
Pins 2 3 disabled 57
C for pci e slots jumper settings 58
C to pci express slots to improve pci performance these two jumpers should be set at the same time refer to the table below for jumper settings the default setting is enabled 58
C1 and j 58
C2 to connect the system management bus 58
Jumper setting definition 58
Jumper settings 58
Megerac license 58
Open disabled 58
Pins 1 2 enabled 58
Pins 1 2 reset 58
Pins 2 3 disabled 58
Pins 2 3 nmi 58
Smbus to pci slots 58
Use jumpers j 58
Watch dog 58
Watch dog jwd1 is a system monitor that can reboot the system when a software application hangs close pins 1 2 to reset the system if an application hangs close pins 2 3 to generate a non maskable interrupt nmi signal for the application that hangs refer to the table below for jumper settings the watch dog must also be enabled in the bios 58
X11ssm f x11ssl f user manual 58
Bios recovery 59
Bios recovery jumper settings 59
Chapter 2 installation 59
Jumper jpg1 allows the user to enable the onboard vga connector the default setting is pins 1 2 to enable the connection refer to the table below for jumper settings the default setting is enabled 59
Jumper setting definition 59
Jumper settings 59
Pins 1 2 enabled 59
Pins 1 2 normal 59
Pins 2 3 bios recovery 59
Pins 2 3 disabled 59
Use jumper jbr1 to recover the bios settings on the motherboard refer to the table below for jumper settings the default setting is normal 59
Vga enable 59
Vga enable disable 59
Bmc enable 60
Bmc enabled 60
Close pin 2 and pin 3 of jumper jpme2 to bypass spi flash security and force the system to operate in the manufacturer mode which will allow the user to flash the system firmware from a host server for system setting modifications refer to the table below for jumper settings the default setting is normal 60
Jumper jpb1 allows the user to enable the embedded aspeed ast2400 baseboard management controller bmc to provide ipmi 2 kvm support on the motherboard refer to the table below for jumper settings the default setting is bmc enable 60
Jumper setting definition 60
Jumper settings 60
Manufacturer mode 60
Manufacturer mode select 60
Pins 1 2 bmc enabled 60
Pins 1 2 normal 60
Pins 2 3 disabled 60
Pins 2 3 manufacturer mode 60
X11ssm f x11ssl f user manual 60
Amber 1 gbps 61
Chapter 2 installation 61
Green 100 mbps 61
Green flashing active 61
Lan leds 61
Lan1 2 activity led right 61
Lan1 2 link led left 61
Lan1 led 61
Lan2 led 61
Led indicators 61
Led state 61
Off no connection 10 mbps 61
Two lan ports lan 1 and lan 2 are located on the i o back panel of the motherboard each ethernet lan port has two leds the green led indicates activity while the other link led may be green amber or off to indicate the speed of the connection refer to the tables below for more information 61
Activity led link led 62
Activity right amber blinking active 62
Green system on 62
In addition to lan 1 and lan 2 an ipmi lan is also located on the i o back panel the amber led on the right indicates activity while the green led on the left indicates the speed of the connection refer to the table below for more information 62
Ipmi dedicated lan leds f versions only 62
Ipmi lan 62
Ipmi lan leds 62
Ipmi lan x8st3 f 62
Lan 1 lan 2 62
Link left green solid amber solid 62
Mbps 1gbps 62
Onboard power led 62
Onboard power led indicator 62
Onboard pwr led 62
System off power cable not connected 62
The onboard power led is located at ledpwr on the motherboard when this led is on the system is on be sure to turn off the system and unplug the power cord before removing or installing components refer to the table below for more information 62
X11ssm f x11ssl f user manual 62
A bmc heartbeat led is located at ledbmc on the motherboard when ledbmc is blinking the bmc is functioning normally refer to the table below for more information 63
Bmc heartbeat led 63
Bmc heartbeat led indicator 63
Chapter 2 installation 63
Green blinking bmc normal 63
Led color definition 63
Before power on 64
Chapter 3 64
No power 64
No video 64
Troubleshooting 64
Troubleshooting procedures 64
Memory errors 65
System boot failure 65
Losing the system s setup configuration 66
When the system becomes unstable 66
Technical support procedures 68
Frequently asked questions 69
Battery installation 70
Battery removal 70
Battery removal and installation 70
Proper battery disposal 70
Returning merchandise for service 71
Chapter 4 72
Introduction 72
Starting the setup utility 72
Main setup 73
Advanced setup configurations 75
Boot feature 75
Power configuration 76
Cpu configuration 77
Cpu thermal configuration 80
Chipset configuration 81
Graphics configuration 81
System agent sa configuration 81
Dmi opi configuration 82
Peg port configuration 82
Memory configuration 83
Pch io configuration 84
Pch slot4 pci e 3 x4 in x8 85
Pch slot5 pci e 3 x4 in x8 85
Pci express configuration 85
Sata configuration 86
Pcie pci pnp configuration 87
Super io configuration 89
Intel server platform services 90
Serial port console redirection 90
Com1 console redirection settings 91
Sol com2 console redirection settings 92
Ems console redirection settings 94
Acpi settings 95
Trusted computing configuration 96
Intel i210 gigabit network connection oc c4 7a 1a 44 ce 97
Iscsi configuration 97
Nic configuration 97
Intel i210 gigabit network connection oc c4 7a 1a 44 cf 98
Nic configuration 98
Change smbios event log settings 100
Event logs 100
View smbios event log 101
System event log 102
Bmc network configuration 103
Secure boot menu 105
Security 105
Save exit 110
Appendix a 112
Beep code error message description 112
Bios beep post codes 112
Bios codes 112
Bios error post beep codes 112
During the post power on self test routines which are performed upon each system boot errors may occur 112
Fatal errors will not allow the system to continue with bootup if a fatal error occurs you should consult with your system manufacturer for possible repairs 112
Ipmi error codes 112
Non fatal errors are those which in most cases allow the system to continue to boot these error messages normally appear on the screen 112
These fatal errors are usually communicated through a series of audible beeps the numbers on the fatal error list correspond to the number of beeps for the corresponding error 112
X11ssm f x11ssl f user manual 112
Appendix b 113
B installing software programs 113
Software installation 113
B superdocto 114
Appendix c 115
Battery handling 115
Standardized warning statements 115
Product disposal 117
Appendix d 118
D overview 118
D recovering the bios block with a usb device 118
D recovering the uefi bios image 118
Uefi bios recovery 118
Appendix e 122
Bios boot block 122
Bios boot block corruption occurrence 122
Dual boot block 122
E introduction 122
E steps to reboot the system by using jumper jbr1 123

Supermicro X11SSL-F-O Инструкция по эксплуатации онлайн

Содержание

Похожие устройства
