Pioneer VSX-920K [10/400] Listening mode buttons
![Pioneer VSX-920K [10/400] Listening mode buttons](/views2/1003088/page10/bga.png)
Controls and displays02
10
En
iPod/iPhone – Lights to indicate iPod/
iPhone is connected (page 45).
8 Tuner controls
BAND – Switches between the AM and FM
radio bands (page 50).
TUNER EDIT –
Use with
TUNE /
,
PRESET /
and
ENTER
to memorize and
name stations for recall
(page 50)
.
TUNE / –
Find radio frequencies
(page 50)
.
PRESET / – Find preset stations
(page 50).
9
MASTER VOLUME
dial
10
PHONES
jack
Connect the headphones. When the
headphones are connected, there is no sound
output from the speakers.
11 Listening mode buttons
AUTO/ALC/DIRECT – Switches between
Auto Surround (page 57), Auto Level
Control mode and Stream Direct mode
(page 60).
STEREO – Switches between stereo
playback and Front Stage Surround
Advance modes (page 60).
STANDARD – Press for Standard decoding
and to switch between the various 2 Pro
Logic IIx and Neo:6 options (page 57).
ADV SURROUND – Switch between the
various surround modes (page 59).
12
iPod iPhone DIRECT CONTROL
Change the receiver’s input to the iPod and
enable iPod operations on the iPod (page 46).
13
MCACC SETUP MIC
jack
Connect the supplied microphone (page 39).
14
iPod/iPhone/USB
terminals
Connect your Apple iPod as an audio and video
source, or connect a USB device for audio and
photo playback (page 35, 36).
15
VSX-1020/VSX-1025 only:
HDMI input
connector
Use for connection to a compatible HDMI
device (Video camera, etc.)(page 34).
16
VSX-920 only:
VIDEO 2 INPUT terminals
Use to connect your portable equipment such
as camcorders, video games and portable
audio/video equipment (page 35).
VSX-1020_SYXCN.book 10 ページ ２０１０年３月１２日 金曜日 午前９時１０分
