![Pioneer VSX-920K Инструкция по эксплуатации онлайн [117/400] 2748](/views2/1003088/page117/bg75.png)
Additional information 12
117
En
English
Français
Deutsch
Nederlands
Italiano
Español
Important information regarding the HDMI connection
There are cases where you may not be able to
route HDMI signals through this receiver (this
depends on the HDMI-equipped component
you are connecting–check with the
manufacturer for HDMI compatibility
information).
If you aren’t receiving HDMI signals properly
through this receiver (from your component),
please try one of the following configurations
when connecting up.
Configuration A
Use component video cables to connect the
video output of your HDMI-equipped
component to the receiver’s component video
input. The receiver can then convert the analog
component video signal to a digital HDMI
signal for transmission to the display. For this
configuration, use the most convenient
connection (digital is recommended) for
sending audio to the receiver. See the
operating instructions for more on audio
connections.
Note
• The picture quality will change slightly
during conversion.
Configuration B
Connect your HDMI-equipped component
directly to the display using an HDMI cable.
Then use the most convenient connection
(digital is recommended) for sending audio to
the receiver. See the operating instructions for
more on audio connections. Set the display
volume to minimum when using this
configuration.
Note
• If your display only has one HDMI
terminal, you can only receive HDMI video
from the connected component.
• Depending on the component, audio
output may be limited to the number of
channels available from the connected
display unit (for example audio output is
reduced to 2 channels for a monitor with
stereo audio limitations).
• If you want to switch the input function,
you’ll have to switch functions on both the
receiver and your display unit.
• Since the sound is muted on the display
when using the HDMI connection, you
must adjust the volume on the display
every time you switch input functions.
When Control with HDMI is
set to ON, the HDMI Input
assignment at Input Setup is
canceled.
• Even when Control with HDMI is set to ON, for Digital In assignment of
HDMI 1 is not canceled, so in this case use the HDMI IN 1 input.
Synchronized operation not
possible using Control with
HDMI function.
• Check the HDMI connections.
• The cable may be damaged.
• Select ON for the Control with HDMI setting (see HDMI Setup on page 64).
• Select ALL for the Control Mode
setting (see HDMI Setup on page 64).
• Turn the TV’s power on before turning on this receiver’s power.
• Set the TV side Control with HDMI setting to on (see TV’s operating
instructions).
Symptom Remedy
