Additional information12
122
En
Auto Surround, ALC and Stream Direct with different input signal formats
The following charts show what you will hear with different input signal formats, depending on the
Stream Direct mode (see Using Stream Direct on page 60) you have selected.
Stereo (2 channel) signal formats
Multichannel signal formats
Input signal format
Auto Surround / ALC /
DIRECT
PURE DIRECT
Surround Back speaker(s): Connected
Dolby Digital Surround
2 Pro Logic llx MOVIE 2 Pro Logic llx MOVIE
DTS Surround Neo:6 CINEMA Neo:6 CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above PCM DIRECT
DVD-A sources As above As above
SACD sources As above As above
Surround Back speaker(s): Not connected
Dolby Digital Surround
2 Pro Logic ll MOVIE 2 Pro Logic ll MOVIE
DTS Surround Neo:6 CINEMA Neo:6 CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above PCM DIRECT
DVD-A sources As above As above
SACD sources As above As above
Input signal format Auto Surround / ALC PURE DIRECT / DIRECT
Surround Back speaker(s): Connected
Dolby Digital EX (6.1 channel flagged) Dolby Digital EX
2 Pro Logic llx MOVIE
a
a.Unavailable with only one surround back speaker connected.
Dolby Digital EX
2 Pro Logic llx MOVIE
a
DTS-ES (6.1 channel sources/6.1 channel flagged)
DTS-ES (Matrix/Discrete) DTS-ES (Matrix/Discrete)
DTS sources (5.1 channel encoding) Straight decoding Straight decoding
DTS-HD sources As above As above
Other 5.1/6.1/7.1 channel sources As above As above
Surround Back speaker(s): Not connected
DVD-A sources/Multi-ch PCM Straight decoding Straight decoding
SACD sources (5.1 channel encoding) As above As above
Other 5.1/6.1/7.1 channel sources As above As above
VSX-1020_SYXCN.book 122 ページ ２０１０年３月１２日 金曜日 午前９時１０分
