Additional information12
132
En
Specifications
Audio section
Rated power output
Front, Center, Surround, Surround back
. . . . . . . . 140 W per channel (1 kHz, 6 Ω, 1 %)
. . . . . . . . . . . . . . . . . . . . . . 100 W per channel
(20 Hz to 20 kHz, 8 Ω, 0.09 %)
Total Harmonic Distortion
. . . . . . . . 0.06 % (20 Hz to 20 kHz, 8 Ω, 95 W/ch)
Guaranteed speaker impedance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Ω to 16 Ω
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB
Frequency Response
. . . . . . . . . . . . . . . . . . . 5 Hz to 100 000 Hz dB
(Pure Direct Mode)
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . 300 mV/47 kΩ
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . 300 mV/2.2 kΩ
Video section
Signal level
Composite . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Component Video . . . . . . . . Y: 1.0 Vp-p (75 Ω),
PB, PR: 0.7 Vp-p (75 Ω)
Corresponding maximum resolution
Component Video . . . . . . . . . . . 1080p (1125p)
(Video convert off)
Tuner section
Frequency Range (FM) . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . .75 Ω unbalanced
Frequency Range (AM). . . . 531 kHz to 1602 kHz
Antenna (AM) . . . . . . . Loop antenna (balanced)
Digital In/Out section
HDMI terminal . . . . . . . . . . . . . .19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . 5 V, 100 mA
USB terminal. . . . . . USB2.0 Full Speed (Type A)
iPod terminal. . . . . USB, and Video (Composite)
ADAPTER PORT terminal. . . . . . . . . 5 V, 100 mA
Integrated control section
Control (SR) terminal. . .Ø 3.5 Mini-jack (MONO)
Control (IR) terminal . . .Ø 3.5 Mini-jack (MONO)
IR signal . . . . . . . High Active (High Level: 2.0 V)
Miscellaneous
Power requirements
. . . . . . . . . . . . . . . AC 220 V to 230 V, 50 Hz/60 Hz
Power consumption . . . . . . . . . . . . . . . . . .245 W
In standby . . . . . . . . . . . 0.4 W (Control OFF)
0.6 W (Control ON)
Dimensions
. . . . . . .420 mm (W) x 158 mm (H) x 379 mm (D)
Weight (without package). . . . . . . . . . . . . 10.2 kg
Number of Furnished Parts
MCACC Setup microphone (APM7008). . . . . . . 1
Remote control unit (AXD7596) . . . . . . . . . . . . . 1
AAA/IEC R03 dry cell batteries . . . . . . . . . . . . . . 2
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
iPod cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
• These specifications are applicable when
the power supply is 230 V.
• Specifications and the design are subject
to possible modifications without notice,
due to improvements.
VSX-1020_SYXCN.book 132 ページ ２０１０年３月１２日 金曜日 午前９時１０分
