![Pioneer VSX-920K Инструкция по эксплуатации онлайн [2/400] 2748](/views2/1003088/page2/bg2.png)
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT
D3-4-2-1-1_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the rear panel.
D3-4-2-1-4*_A1_En
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 40 cm at top, 10 cm at rear, and 20 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
D3-4-2-1-2-2*_A1_En
Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified
service personnel.
IMPORTANT: THE MOULDED PLUG
This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 10 amp fuse is fitted in this plug. Should
the fuse need to be replaced, please ensure that the replacement fuse has a rating of 10 amps and that it is approved by ASTA or BSI to
BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug
must not be used until a replacement cover is obtained. A replacement fuse cover can be obtained from your local dealer.
If the fitted moulded plug is unsuitable for your socket outlet, then the fuse shall be removed and the plug cut off and disposed of
safely. There is a danger of severe electrical shock if the cut off plug is inserted into any 13 amp socket.
If a new plug is to be fitted, please observe the wiring code as shown below. If in any doubt, please consult a qualified electrician.
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
Blue : Neutral Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in
your plug, proceed as follows;
The wire which is coloured BLUE must be connected to the terminal which is marked with the
letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the
letter L or coloured RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
VSX-1020_SYXCN.book 2 ページ ２０１０年３月１２日 金曜日 午前９時１０分
Содержание
- Contents 4
- Adjusting the sound and picture quality as desired 7
- Basic playback page 44 7
- Before you start 7
- Changing the osd display language osd language page 39 7
- Connecting the components 7
- Connecting the speakers 7
- Determining the speakers application page 17 7
- Flow of settings on the receiver 7
- Making maximum use of the remote control 7
- Mcacc speaker settings 7
- Other optional adjustments and settings 7
- Power on 7
- The input setup menu page 42 7
- Before you start 8
- Caution 8
- Checking what s in the box 8
- Installing the receiver 8
- Loading the batteries 8
- Character display 9
- Controls and displays 9
- Front panel 9
- Indicators 9
- Input selector dial 9
- Multi zone controls 9
- Remote sensor 9
- Speakers 9
- U standby on 9
- Ipod iphone direct control 10
- Ipod iphone usb terminals 10
- Listening mode buttons 10
- Master volume dial 10
- Mcacc setup mic jack 10
- Phones jack 10
- Tuner controls 10
- Vsx 1020 vsx 1025 only hdmi input connector 10
- Vsx 920 only video 2 input terminals 10
- Digital format indicators 11
- Display 11
- Listening mode indicators 11
- Multi zone 11
- Phase control 11
- Program format indicators 11
- S rtrv 11
- Signal indicators 11
- Analog signal indicators 12
- Character display 12
- Input function indicators 12
- Master volume level 12
- Matrix decoding format indicators 12
- Remote control mode indicator 12
- Scroll indicators 12
- Speaker indicators 12
- Tuner indicators 12
- Input function buttons 13
- Multi operation use to perform multi operations page 81 13
- Receiver controls 13
- Remote control 13
- Tv control buttons 13
- U receiver 13
- Zone 2 13
- I j k l enter 14
- Listening mode controls 14
- Master volume 14
- Operating range of remote control unit 14
- Receiver controls 14
- Remote control led 14
- Tv ctrl 14
- Connecting your equipment 15
- Important 15
- Rear panel 15
- Caution 16
- Important 16
- A 9 channel surround system front height 17
- B 9 channel surround system front wide 17
- C 7 channel surround system speaker b connection 17
- Determining the speakers application 17
- D 5 channel surround system front bi amping connection high quality surround 18
- E 5 channel surround system zone 2 connection multi zone 18
- Important 18
- Other speaker connections 18
- Placing the speakers 19
- Some tips for improving sound quality 19
- Bare wire connections 20
- Caution 20
- Connecting the speakers 20
- Loosen terminal and insert exposed wire 20
- Push open the tabs and insert exposed wire 20
- Release the tabs 20
- Tighten terminal 20
- Twist exposed wire strands together 20
