Tcl L50C1US [18/53] Menu operation

Network

You can set up your TV so that it can access the Internet

through your local area network (LAN) using a wired or

wireless connection.

Ethernet settings: you can attach your TV to your LAN

using cable in three ways:

- You can attach your TV to your LAN by connecting

the LAN port on your TV to an external modem

using a Cat 5 cable.

- You can attach your TV to your LAN by connecting

the LAN port on your TV to an IP Sharer which is

connected to an external modem. Use Cat 5 cable for

the connection.

- Depending on how your network is configured,

you may be able to attach your TV to your LAN by

connecting the LAN port on your TV directly to a

network wall outlet using a Cat 5 cable. Note that

the wall outlet is attached to a modem or router

elsewhere in your house.

Select Settings > Network > Ethernet settings and

press OK, and then congure the IP settings to connect

to a wired network. You can also check the network

information here.

Wireless settings: To connect your TV to your network

wirelessly, you need a wireless router or modem and a

wireless LAN adapter.

Note: If your TV doesn’t have an in-built wireless

adapter, then

you need a

wireless USB dongle (which is

sold separately)

. Connect

the USB dongle to your TV’s

USB port.

Select

Settings >

Network, then select Wireless

settings to connect to a wireless network. you can set

up the wireless network connection accordingly.

• WiFi switch: Select WiFi switch and press OK/► to

enter, use ▲/▼ to set it to On, then below options are

available. Otherwise, they are hided.

• Scan: Select Wireless settings > Scan, then press

OK/►, the TV will scan all access points within

range. The access points found by the TV will be

displayed. Select an available access point, then

press OK to connect the TV to it.

Menu Operation

CH +/- button. Press OK/► to display Channel skip

menu. Press ▲/▼ to select a channel and press OK

to check the box.

Channel edit: Press OK/► to display the channel list.

Press ▲/▼ to select a channel you want to edit, then

press OK to enter. Press ▲/▼ to select Channel

name, then press OK to access the virtual keyboard

and edit the channel name, and highlight OK and

press OK to conrm. When you have nished, press

BACK to return.

Channel delete: Press OK/► to display Channel list.

Press ▲/▼ to select a channel you want to delete,

then press OK to delete the channel.

Channel diagnostics (only for digital channels): Press

OK/► to display some signal information on current

digital channel, such as signal strength, frequency, etc.

Time shift: Set Time Shift to On or Off. Default setting

is On. For details, please see the introduction of Time

Shift on page 13.

Subtitle: This enables subtitle for digital TV channels.

Select Subtitle, press OK/► to display its submenus:

• Subtitle: Press OK/► to enter, press ▲/▼ to turn On

or Off the subtitles. When Subtitle is set to On, you

can enable subtitle languages on digital TV channels:

1. Press ▲/▼ to select Digital subtitle language.

2. Press OK/► to enter, press ▲/▼ to select a subtitle

language as your preferred language.

3. Press ▲/▼ to select Digital subtitle language 2nd.

4. Press OK/► to enter, press ▲/▼ to select a

secondary subtitle language.

5. Press Exit or BACK to return to previous menu.

Note: Press SUBTITLE on the remote control to

directly select a subtitle language available for

selected digital TV program.

• Subtitle type: press OK/► to enter, press ▲/▼

to select a subtitle type. You can select Hearing

impaired to display the hearing impaired subtitle with

your selected language.

Teletext: press OK/► to display its submenu.

• Decoding page language: Select a proper type of

language in which Teletext will display.

• Digital teletext language: For digital TV channels,

your TV could zap to a service with multiple initial

Teletext pages in different languages. This function

allows you to select an available language as primary

language which relates to different initial Teletext

page.
