Tyros / TRS-MS01
11
● Lower Case Side
Location
Parts No.
W.H name
Discription Notes
Source Destination
260 (WA60900) INLET Power supply unit-CN1 INLET-CN3 Gray wire is adjusted to Pin 1 mark (
mark)
(2P)
270 (WA60890) SW Power supply unit-CN2 AJACK-CN1 Red wire is adjusted to Pin 1 mark (
mark)
(9P)
280 (V919700) SPL AJACK-CN6 SPOUTL-CN1 Red wire is adjusted to Pin 1 mark ( mark)
(2P)
290 (WA60810) HP AJACK-CN8 PHONES-CN4 Red wire is adjusted to Pin 1 mark (
mark)
(6P)
300 (V926360)
VR2 (14P)
AJACK-CN5 MICVRSUB-CN6
310 (V919790) FDD1 AJACK-CN2 3.5"FDD Unit (power) Red wire is adjusted to Pin 1 mark (
mark)
(2P)
320 (WA61040) POW AJACK-CN3 REG-CN1 The direction whith dose not have a ferrite core is
(4P) AJACK-CN3 connected.
325 (V962540) POW2 REG-CN2 DM-CN1 Red wire is adjusted to Pin 1 mark ( mark)
(7P)
330 WA120900 FCC4 AJACK-CN4 DM-CN9 Insulated plate side is a PCB end side
(24P)
340 (WA60940) SPR AJACK-CN7 SPOUTR-CN5 Red m wire is adjusted to Pin 1 mark (
mark)
(3P) The direction whith dose not have a ferrite core is
AJACK-CN7 connected.
350 WA121000 FCC5 DM-CN2 DJACK-CN1 Insulated plate side is a PCB end side
(21P)
360 (WA61010) VIDEO DJACK-CN2 DM-CN13
Conduction line is adjusted to Pin 1 mark ( mark)
(2P) The direction with a ferrite core is DJACK-CN2 con-
nected.
365 (WA61080)
USB1(4P)
DM-CN21 & PCB DJACK-CN4, CN5
370 WA120200
FDD(34P)
DM-CN3 3.5" FDD Unit
380 (WA60990) MKS DM-CN8 EMKS-N -CN1 Red wire is adjusted to Pin 1 mark ( mark)
(7P) The direction whith dose not have a ferrite core is DM-
CN8 connected.
390 V9197600 PC PC-CN2 EMKS-N -CN5 Red wire is adjusted to Pin 1 mark ( mark)
(3P)
400 (V919630) MK2 61L-CN5 EMKS-N -CN6 edge mark is adjusted to Pin 1 mark ( mark)
(7P)
410 (V919640) MK3 61H-CN2 EMKS-N -CN3 edge mark is adjusted to Pin 1 mark ( mark)
(5P)
420 (V919650) MK4 61H-CN1 EMKS-N -CN2 edge mark is adjusted to Pin 1 mark ( mark)
(12P)
A V8696200 Relay 61L-CN4 61H-CN3 edge mark is adjusted to Pin 1 mark ( mark)
B V9357100
PC sensor
PC sensor PC-CN1 Carbon side is a PCB end side
(2P)
650 (WA12570) GND3 DM Screw stop
Power supply shield cover
660 (WA53110) GND9 INLET BOX Screw stop
Power supply shield cover
C (WA12590) GND5 AJACK-G3
Power supply shield cover
D
WA126200
GND8 AJACK-G4 PNL-CN7
Parts in parenthese are not supplied as the replacement parts.
