Scarlett SC-050 [3/8] Power selector

CAUTION:

· Do not cover the appliance when is use.

ASSEMBLING

· First put the unit upside down.

· Install multidirectional rolling wheels to each end

between the first and the second groups of the

radiating flanges.

· Let the  shape screw surrounding the dome of the

radiating flanges. Then insert it into two holes of the

supporting plate.

· Insert the butterfly nuts and screw them tightly counter

clockwise.

USING THE APPLIANCE

· Set the thermostat to  position and power selector to  position, insert the plug to the

power supply.

POWER SELECTOR

· You can adjust power of work of an oil heater, using power regulator:

- Off;

- minimal power;

- II  medium

power;

-  and II

simultaneously 

maximum power.

THERMOSTAT

· Set the thermostat to position.

· When the temperature rises to which you are satisfied with, slowly turn the thermostat

counterclockwise until the indicator lights is out, and the room temperature thus can keep

constant.

· If you want to change the room temperature, you can make another regulation: turn the

thermostat clockwise to rise the temperature and counterclockwise to lower it, or turn the

power selector to  position.

FAN SWITCH

· This appliance is equipped with additional function for convection warm air. To activate

this function, simply press the fan switch in front of the oil heater.

- . Off;

-. On.

MODEL POWER REGULATION

RANGE (W)

SC-050 800/1200/2000

SC-052 1000/1500/2500
