10
Quick adviser
The quick adviser (under the lid on the sewing machine) provides various descriptions
such as basic machine operations.
Accessing the quick adviser
z
Quick adviser
(Stored inside)
For model XXX26C/XXX34C
For model XXX26D/34D/SuperJ26/34
Pull the top of the lid towards yourself to open it.
Quick adviser
(Stored inside)
Note:
Do not pull down the top of the lid with extreme force. The lid may break.•
If the lid has been removed from the •
machine, fit the lid into the corresponding
area of the machine, and then push it
straight in until it snaps into place.
