Connections and settings
15
VQT3B75
≥ Refer to the operating instructions of the hub or router.
≥ You can perform this setup anytime by selecting “Network Easy Setting”
in the Setup menu. (> 33)
≥ You can redo these settings individually using “Network Settings”.
(> 33)
≥ Do not use this unit or Wireless LAN adaptor to connect to any wireless
network for which you do not have usage rights.
During automatic searches in a wireless network environment,
wireless networks (SSID) for which you do not have usage rights may
be displayed; however, using these networks may be regarded as
illegal access.
≥ After performing network settings on this unit, the settings (encryption
level, etc.) of the Wireless router might change.
When you have trouble getting online on your PC, perform the network
settings on your PC in accordance with the settings of Wireless router.
≥ Please be aware that connecting to a network without encryption may
result in the content of the communication being illegitimately viewed by
a third party, or the leaking of data such as personal or secret
information.
Occasionally, Panasonic may release updated firmware for
this unit that may add or improve the way a feature
operates. These updates are available free of charge.
This unit is capable of checking the firmware automatically
when connected to the Internet via a broadband connection.
When a new firmware version is available, the following
message is displayed.
To update the firmware
Press [HOME] > select “Setup” > select “Player
Settings” > select “Others” > [OK] > select “Firmware
Update” > [OK] > select “Update Now”
DO NOT DISCONNECT the unit from the AC power or
perform any operation while the update takes place.
After the firmware is installed, “FINISH” will be displayed on
the unit’s display. Unit will restart and the following screen
will be displayed.
≥ If downloading on this unit fails or this unit is not connected to the
Internet, then you can download the latest firmware from the
following website and burn it to a CD-R to update the firmware.
http://panasonic.jp/support/global/cs/
(This site is in English only.)
To show the firmware version on this unit. (> 34, “System
Information”)
≥ Downloading will require several minutes. It may take longer or
may not work properly depending on the connection environment.
≥ If you do not want to check for the latest firmware version, set
“Automatic Update Check” to “Off”. (> 34)
Firmware updates
New firmware is available.
Please update firmware in Setup.
The firmware has been updated.
Current Version:
x.xx
RETURN
OK
DMP-BDT310_110EB-VQT3B75.book 15 ページ ２０１１年２月２１日 月曜日 午後５時１７分
