Tcl L70C2US [10/45] Getting started

Network Settings

AfteryouconnectyourhomenetworktotheTV,followthestepsbelowtocongurethenetworksettingsofyourTV.

Note: the wireless network connect won't work if your TV is already connected to a wired network.

Connecting to a wireless network

1. Press on the remote control. The Smart TV homepage is displayed.

2. Press ▲/▼tomove to the Settings area, select Settings and press OK to enter.

3. Move to the Device area, select Network and press OK to enter. The Network menu is displayed.

4. Select Wi-Fi and press OK to enter.

5. Set Wi-Fi to On. All available wireless networks will be displayed.

6. Press ▲/▼tohighlightthenameofyourwirelessnetworkandpressOK.

7. Using the on-screen keyboard and the remote, enter your network's password, then highlight Enter on the on-

screen keyboard and press OK. Once connected, the wireless network will be saved. Next time when you

connect to the same network, you do not have to re-enter the password.

8. Press to close the menu and return to the Smart TV homepage.

Connecting to a wired network

1. From the Network menu, select Ethernet and press OK to enter.

2. Press ▲/▼toselectAdvanced options and press OK.

3. Press▲/▼toselectProxy settings and press OK.

4. Select MANUAL, using the on-screen keyboard and the remote, enter your network's proxy information step by

step.

5. Press▲/▼toselectIP settings and press OK.

6. Select DHCP or STATIC. If you select STATIC, you must enter your network's IP address, gateway, network prefix

length, DNS1, and DNS2 step by step.

7. Press to close the menu and return to the Smart TV homepage.

Detecting your network status

1. From the Network menu, select Network Detection and press OK to enter.

2. The Network Detection screen displays the connection method of your network connection.

3. Press to close the menu and return to the Smart TV homepage.

Getting Started
