Animo WKT 20N VA [11/15] Temperature protection

Rev. 4.0 01/2008

WKTn / WKT-Dn

7. TEMPERATURE PROTECTION

There is a temperature protection in the machine that can be

accessed from the outside of the machine. This protection is

located at the back of the machine (fig. 5A). It is activated when

the temperature gets too high. The most common cause for

activating the security is scale that has not been removed in time.

If the temperature protection is activated, you should proceed with

the following steps:

1. Let the unit cool down.

2. Unscrew the black protection cover.

3. Push the button that now appears, replace its black cover

and fasten it tightly.

If the dry-boil protection triggers owing to

increased scale deposits, descale the appliance.

See chapter 6.1. Consult your dealer if the fault was caused by a problem other than the dry-boil

protection being triggered.

8. TRANSPORT

The transport of the machine should be done as follows:

1. Switch the machine off and remove the plug from the wall socket.

2. Close the tap of the cold water supply and disconnect the water

hose (VA).

3. Remove the cover of the reservoir.

4. Turn the machine upside down to let the remaining water out

above the sink.

5. Place the cover again.

6. The machine is now ready for transportation.

7. Proceed with section 3 “INSTALLATION” to reinstall the machine.

fig. 6

fig. 5
